Product Introduction
The Ovation 1C31113G04 Analog Input Module is a high-performance component designed specifically for the Ovation distributed control system (DCS). It serves as a critical interface for capturing and processing analog signals from field instruments, enabling precise monitoring and control in industrial automation environments. The module supports multiple channels of analog input, converting real-world electrical signals into digital data that the control system can use for analysis and decision-making.
This module is engineered for reliability, accuracy, and compatibility with a wide range of sensors and transducers. Its robust design ensures stable operation even in demanding environments such as power generation plants, petrochemical facilities, and other process industries.
Product Specifications
| Parameter | Specification |
|---|---|
| Model Number | 1C31113G04 |
| Module Type | Analog Input Module |
| Number of Input Channels | Typically 8 or 16 (depending on config) |
| Input Signal Types | Voltage, Current (e.g., 4-20mA, 0-10V) |
| Accuracy | ±0.1% FS (Full Scale) |
| Resolution | 16-bit |
| Isolation | Galvanic isolation between channels |
| Power Supply | 24 V DC (typical) |
| Communication Interface | Backplane bus interface |
| Operating Temperature | -20°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Humidity | 5% to 95% non-condensing |
| Dimensions (H x W x D) | 121 x 51 x 140 mm |
| Weight | 0.3 kg |
Applications
-
Power Generation Plants: For continuous monitoring of temperature, pressure, flow, and other vital parameters.
-
Oil & Gas Industry: Used in refining and processing units for accurate control of analog signals.
-
Chemical Processing: To track critical variables for safe and efficient chemical reactions.
-
Water & Wastewater Treatment: For precise input data from various sensors in water quality and flow measurement.
-
Manufacturing Automation: Ensures reliable analog data input for controlling production lines and machinery.
-
HVAC Systems: Integrated for monitoring environmental conditions to optimize system performance.
Advantages
-
High Accuracy and Reliability: Ensures precise measurement essential for critical industrial processes.
-
Robust Design: Built to withstand harsh industrial environments including temperature extremes and electrical noise.
-
Wide Compatibility: Supports various signal types and interfaces seamlessly with the Ovation DCS.
-
Easy Installation and Maintenance: Compact design with plug-and-play capability reduces downtime.
-
Isolation and Protection: Galvanic isolation protects the system and enhances signal integrity.
-
Flexible Configuration: Multiple channels allow customization for specific application needs.
-
Long Service Life: Manufactured to rigorous standards ensuring dependable operation over years.
-
Enhanced Safety: Reduces risk of erroneous data through stable signal processing.
Frequently Asked Questions (FAQ)
-
What types of signals does the 1C31113G04 module support?
It supports common analog signals such as 4-20mA current loops and 0-10V voltage signals. -
How many input channels does this module have?
Typically, it provides 8 or 16 input channels, depending on the specific configuration. -
Is the module compatible with all Ovation control systems?
Yes, it is designed to fully integrate with the Ovation distributed control system. -
What is the operating temperature range?
The module operates safely between -20°C and +70°C. -
Does the module provide electrical isolation?
Yes, it features galvanic isolation between input channels and the backplane. -
How precise are the measurements?
The module offers an accuracy of ±0.1% of full scale, suitable for most industrial needs. -
What are the physical dimensions of the module?
It measures 121 x 51 x 140 mm. -
What power supply voltage does the module require?
It requires a 24 V DC power supply, which is standard for Ovation modules. -
Can this module be used in hazardous environments?
It is designed for industrial use but should be installed in accordance with local safety and hazardous area standards. -
How easy is it to replace or upgrade the module?
The module supports plug-and-play installation, making replacement and upgrades straightforward.
Related Models (Same Series / Similar Functionality)
| Model Number | Description | Channels | Signal Type | Weight (kg) | Dimensions (mm) (HxWxD) |
|---|---|---|---|---|---|
| 1C31113G01 | Analog Input Module, basic | 8 | 4-20mA, 0-10V | 0.5 | 130 x 40 x 200 |
| 1C31113G02 | Analog Input Module, high density | 16 | Voltage, Current | 0.6 | 130 x 40 x 200 |
| 1C31113G05 | Analog Input Module with extended range | 8 | 4-20mA, 0-20mA | 0.5 | 130 x 40 x 200 |
| 1C31114G04 | Analog Output Module | 8 | Voltage, Current | 0.5 | 130 x 40 x 200 |
| 1C31112G03 | Digital Input Module | 16 | Discrete Signals | 0.4 | 130 x 40 x 200 |
| 1C31115G06 | Analog Input with Diagnostics | 8 | Current, Voltage | 0.55 | 130 x 40 x 210 |
Popular Models from Ovation Brand
| Model Number | Description | Channels | Signal Type | Weight (kg) | Dimensions (mm) (HxWxD) |
|---|---|---|---|---|---|
| 1C31110G01 | Digital Output Module | 16 | Discrete Output | 0.4 | 130 x 40 x 200 |
| 1C31120G04 | Power Supply Module | – | 24 V DC | 1.0 | 150 x 60 x 250 |
| 1C31116G02 | Universal Input Module | 8 | Analog & RTD | 0.6 | 130 x 40 x 210 |
| 1C31117G03 | Temperature Input Module | 16 | RTD / Thermocouple | 0.5 | 130 x 40 x 200 |
| 1C31118G01 | Communication Interface Module | – | Ethernet/Serial | 0.7 | 130 x 50 x 210 |
| 1C31119G02 | Alarm Annunciator Module | – | Discrete Signals | 0.45 | 120 x 40 x 190 |
