Product Introduction
The Ovation 1C31113G06 Analog Input Module is a high-performance input module used in Emerson’s Ovation Distributed Control System (DCS). Known for its exceptional reliability and precision, this module is designed to acquire and process analog signals from a wide variety of field instruments, such as temperature sensors, pressure transmitters, flow meters, and other process variables.
The 1C31113G06 module seamlessly integrates with the Ovation DCS architecture, providing accurate and real-time data that supports critical process automation and control. The module is widely used in industries requiring high availability and performance, including power generation, water treatment, petrochemical, and other process industries.
Its robust design, excellent signal conditioning capabilities, and flexible input configuration make it an essential component in modern automation solutions.
Product Parameters
| Parameter | Specification |
|---|---|
| Model Number | 1C31113G06 |
| Type | Analog Input Module |
| Input Channels | 16 channels |
| Input Signal Type | 4-20 mA, 0-10 V, RTD, Thermocouple (configurable) |
| Resolution | 16-bit |
| Input Impedance | >100 kΩ |
| Isolation | 1500 V RMS channel-to-channel and channel-to-ground |
| Accuracy | ±0.1% of reading |
| Sampling Rate | Configurable, typically 10 ms/channel |
| Power Consumption | Approx. 8 W |
| Operating Temperature Range | 0 °C to +60 °C |
| Storage Temperature | -40 °C to +85 °C |
| Relative Humidity | 5% to 95% non-condensing |
| Protection | Internal surge protection, noise filtering |
| Dimensions | 260 × 32 × 176 mm |
| Weight | 0.8 kg |
Product Applications
The Ovation 1C31113G06 Analog Input Module is used across various industries that demand precise and reliable analog signal processing:
-
Power Generation: Monitoring and controlling boiler systems, turbines, heat exchangers, and auxiliary systems in fossil fuel, nuclear, and renewable power plants.
-
Water and Wastewater Treatment: Process control for pumps, chemical dosing systems, flow regulation, and filtration units.
-
Oil & Gas: Acquisition of critical field data from pipelines, compressors, separators, and refining equipment.
-
Chemical & Petrochemical: Process control of reactors, distillation columns, and chemical blending systems.
-
Pharmaceutical: Monitoring of temperature, humidity, and batch processing systems.
-
OEM and Skid Systems: Integrated into packaged equipment for modular automation solutions.
Product Advantages
-
High Accuracy: Provides highly accurate data with ±0.1% precision, supporting stable process control.
-
Flexible Signal Support: Compatible with a wide range of analog input types including voltage, current, RTD, and thermocouple signals.
-
Excellent Noise Immunity: Built-in noise filtering and electrical isolation to ensure reliable operation in electrically noisy environments.
-
Robust Design: Designed for industrial environments with protection against temperature extremes, vibration, and electrical surges.
-
Seamless Integration: Fully compatible with Emerson’s Ovation DCS, ensuring effortless system integration and minimal commissioning time.
-
High Channel Density: 16-channel capacity reduces hardware footprint and optimizes cabinet space.
-
Flexible Configuration: Field-configurable for a variety of input types and ranges, simplifying engineering design.
-
Reliable Performance: Proven reliability in mission-critical applications, delivering years of trouble-free operation.
-
Scalability: Supports system expansion as plant needs grow, protecting your investment.
-
Easy Maintenance: Modular design with clear diagnostics simplifies troubleshooting and minimizes downtime.
Frequently Asked Questions (FAQ)
-
What is the primary function of the 1C31113G06 Analog Input Module?
It acquires and converts analog signals from field instruments into digital values for use in the Ovation DCS. -
How many input channels does this module have?
It supports 16 analog input channels. -
What types of input signals can it process?
It can handle 4-20 mA current signals, 0-10 V voltage signals, RTD sensors, and thermocouples. -
Is this module isolated?
Yes, it provides 1500 V RMS isolation between channels and from channels to ground. -
What is the resolution of the module?
It features a 16-bit resolution for high accuracy measurements. -
Can this module operate in harsh environments?
Yes, it is designed for industrial use with an operating temperature range of 0 °C to +60 °C. -
How does this module integrate with the Ovation DCS?
It is fully compatible and integrates seamlessly via Ovation’s native control architecture. -
Is this module suitable for safety-critical applications?
Yes, it is widely used in applications where reliability and accuracy are essential, such as power plants and refineries. -
What is the physical size of this module?
Its dimensions are 260 × 32 × 176 mm, and it weighs 0.8 kg. -
Can the module be field-configured for different input types?
Yes, it supports field configuration for various signal types to adapt to diverse application needs.
Related Models from the Same Series or Family
| Model Number | Description | Channels | Input Signal Type | Isolation |
|---|---|---|---|---|
| 1C31113G05 | Analog Input Module | 16 | 4-20 mA, 0-10 V | 1500 V RMS |
| 1C31113G06 | Analog Input Module | 16 | 4-20 mA, 0-10 V, RTD, TC | 1500 V RMS |
| 1C31110G03 | Isolated Analog Input Module | 8 | 4-20 mA | 2000 V RMS |
| 1C31224G01 | Analog Output Module | 8 | 4-20 mA | 1500 V RMS |
| 1C31150G01 | High-Density Analog Input | 32 | 4-20 mA | 1500 V RMS |
| 1C31125G02 | Mixed Signal Module | 16 AI + 8 DI | 4-20 mA, DI | 1500 V RMS |
Popular Models from the Same Brand (Emerson Ovation Series)
| Model Number | Description | Channels | Input/Output Type | Isolation |
|---|---|---|---|---|
| 1C31113G06 | Analog Input Module | 16 | 4-20 mA, 0-10 V, RTD, TC | 1500 V RMS |
| 1C31110G03 | Isolated Analog Input | 8 | 4-20 mA | 2000 V RMS |
| 1C31224G01 | Analog Output Module | 8 | 4-20 mA | 1500 V RMS |
| 1C31129G03 | Digital Input Module | 32 | 24 VDC | 1500 V RMS |
| 1C31116G01 | Digital Output Module | 32 | 24 VDC | 1500 V RMS |
| 1C31147G01 | RTD Input Module | 16 | RTD | 1500 V RMS |
