Product Overview
The Ovation 1C31124G01 Digital Output Module is a key component of Emerson’s Ovation distributed control system (DCS), designed to provide reliable digital control signals to field devices. It supports critical operations by converting control logic into precise output actions, ensuring dependable system performance in demanding industrial environments. With its rugged design and seamless integration, it is suitable for a wide range of automation and process control applications.
Key Features
-
Provides accurate digital output control for field devices
-
Seamless integration within the Ovation DCS architecture
-
Supports multiple output channels for flexible configurations
-
Built-in diagnostic and fault monitoring functions
-
Rugged design for continuous operation in industrial environments
-
Long service life with reliable electronic components
Technical Specifications
| Item | Specification |
|---|---|
| Model Number | 1C31124G01 |
| Series | Ovation |
| Type | Digital Output Module |
| Dimensions | 250 × 40 × 180 mm |
| Weight | 1.1 kg |
| Channels | 16 digital outputs (typical) |
| Output Type | Voltage/current-based digital signals |
| Output Voltage | 24 VDC nominal |
| Output Current | 0.5 A per channel (typical) |
| Isolation | Channel-to-channel and channel-to-system isolated |
| Operating Temperature | 0 °C to +60 °C |
| Storage Temperature | -20 °C to +85 °C |
| Humidity | 5% to 95% non-condensing |
| Protection Features | Short-circuit, overvoltage, thermal shutdown |
| Compliance | CE, UL, RoHS |
Industry Applications
-
Power Generation – control of relays, breakers, and actuators
-
Oil & Gas – valve and motor control in automation systems
-
Petrochemical – reliable digital outputs for process equipment
-
Water & Wastewater – pump and treatment system control
-
Industrial Manufacturing – machinery and production line automation
Advantages
-
Provides reliable and precise control of field devices
-
Designed for long-term operation under industrial conditions
-
Built-in isolation enhances system protection and reliability
-
Supports multiple digital outputs for flexible configurations
-
Seamless integration with Ovation DCS infrastructure
Frequently Asked Questions (FAQ)
Q1: What is the main function of the 1C31124G01 module?
It provides digital output signals for controlling field devices in an Ovation DCS.
Q2: How many output channels does it support?
Typically, it supports 16 digital output channels.
Q3: What is the output voltage?
The nominal output voltage is 24 VDC.
Q4: What is the maximum output current per channel?
0.5 A per channel (typical).
Q5: Is the module electrically isolated?
Yes, it features channel-to-channel and channel-to-system isolation.
Q6: What are the dimensions of the module?
250 mm × 40 mm × 180 mm.
Q7: What is the weight of the module?
1.1 kg.
Q8: Can it operate in harsh environments?
Yes, it is designed for 0 °C to +60 °C operation with industrial-grade protection.
Q9: What protection features are included?
Short-circuit protection, overvoltage protection, and thermal shutdown.
Q10: Which industries commonly use this module?
Power generation, petrochemical, oil & gas, water treatment, and manufacturing.
