Product Overview
The Ovation 1C31129G01 Analog Output Module is a highly reliable and precise component designed for use in Emerson Ovation Distributed Control Systems (DCS). It is engineered to provide analog output signals that interface with field devices such as control valves, dampers, actuators, and other process equipment in various industrial automation settings.
Capable of generating accurate analog outputs — typically 4–20 mA signals — the module allows the Ovation DCS to exert fine control over critical process variables such as flow, temperature, pressure, and chemical dosing. The 1C31129G01 delivers excellent signal integrity, wide operational temperature range, and robust construction, making it suitable for harsh industrial environments.
As part of the Ovation control architecture, this analog output module integrates seamlessly with other I/O components, CPUs, and networked systems, contributing to the overall reliability, flexibility, and performance of the plant’s automation platform.
Product Specifications
| Parameter | Value |
|---|---|
| Model | 1C31129G01 |
| Product Type | Analog Output Module |
| Compatible System | Emerson Ovation DCS |
| Number of Channels | 8 Analog Output Channels |
| Output Signal Type | 4–20 mA (current loop), isolated |
| Resolution | 12-bit |
| Output Load Range | 0–750 Ohms |
| Accuracy | ±0.1% of span |
| Calibration | Factory calibrated; field adjustable |
| Diagnostics | Built-in diagnostics and fault detection |
| Redundancy Support | Yes (used in redundant I/O configurations) |
| Operating Voltage Range | 24 VDC nominal |
| Power Consumption | < 6 W |
| Isolation | Channel-to-channel and channel-to-ground isolation |
| Operating Temperature Range | -20 °C to +60 °C |
| Storage Temperature Range | -40 °C to +85 °C |
| Humidity (Non-condensing) | 5% to 95% RH |
| EMC Compliance | IEC 61000, CE certified |
| Certifications | UL, CSA, CE |
| Mounting | DIN-rail or chassis-based in Ovation I/O racks |
| Dimensions (W × H × D) | 40 × 260 × 200 mm |
| Weight | 1.1 kg |
| Mean Time Between Failures (MTBF) | > 500,000 hours |
Applications
The Ovation 1C31129G01 Analog Output Module is widely used in a range of industries where precise control of analog signals is essential for maintaining process quality and safety:
-
Power Generation
Steam turbine control, boiler management, balance-of-plant applications. -
Water & Wastewater Treatment
Flow control, chemical dosing, and level regulation. -
Oil & Gas
Upstream and downstream automation, pipeline control, separator systems. -
Chemical Processing
Precise control of temperature, pressure, and chemical flows. -
Pulp & Paper
Process optimization and machine control. -
Metals & Mining
Actuator control for smelters, refining, and extraction systems. -
Pharmaceuticals
Accurate process control in manufacturing and clean-room environments.
Product Advantages
-
High Precision Output
12-bit resolution with ±0.1% accuracy ensures fine control of process variables. -
Reliable Isolation
Channel-to-channel and channel-to-ground isolation protects against signal interference and ground loops. -
Built-in Diagnostics
Real-time fault detection enhances system safety and simplifies troubleshooting. -
Seamless Ovation Integration
Native compatibility with Emerson Ovation DCS reduces engineering and commissioning time. -
Redundancy Ready
Supports deployment in redundant I/O configurations for high availability systems. -
Wide Operating Range
Suitable for harsh environments with -20 °C to +60 °C operational range. -
Low Maintenance
Factory-calibrated and designed for long operational life with minimal servicing. -
Flexible Installation
Easily mounted on DIN-rails or installed in Ovation I/O chassis. -
Certified & Compliant
Meets international industrial standards (UL, CSA, CE), ensuring safe operation. -
Field Proven
Deployed globally across thousands of critical applications.
Frequently Asked Questions (FAQ)
-
What is the output range of the 1C31129G01 Analog Output Module?
The module provides 4–20 mA analog outputs on each of its 8 channels. -
Can the module be used in redundant systems?
Yes, it supports full I/O redundancy when configured within an Ovation DCS. -
What is the resolution of the output signal?
It features 12-bit resolution for precise control. -
Is the module factory calibrated?
Yes, it is factory calibrated but can also be field-adjusted if needed. -
What types of field devices can be controlled?
It controls a wide variety of actuators, valves, dampers, and other analog-driven field devices. -
Does it support diagnostic features?
Yes, the module has built-in diagnostics to detect faults and signal errors. -
Is isolation provided between channels?
Yes, both channel-to-channel and channel-to-ground isolation is provided. -
What type of cabling is required?
Standard shielded twisted-pair cabling is typically used for 4–20 mA outputs. -
How long is the service life of the module?
The MTBF is greater than 500,000 hours, supporting many years of reliable operation. -
Does the module comply with industry standards?
Yes, it is CE, UL, and CSA certified and meets EMC requirements.
Related Models from the Same Series or Category
| Model | Product Type | Channels | Output Type | Dimensions (W×H×D) | Weight |
|---|---|---|---|---|---|
| 1C31129G03 | Analog Output Module | 8 | 4–20 mA | 40×260×200 mm | 1.10 kg |
| 1C31206G01 | Analog Input Module | 16 | 4–20 mA | 40×260×200 mm | 1.05 kg |
| 1C31197G01 | Analog Output Module | 16 | 4–20 mA | 40×260×200 mm | 1.15 kg |
| 1C31234G01 | RTD Input Module | 8 | RTD | 40×260×200 mm | 1.05 kg |
| 1C31116G01 | Digital Output Module | 32 | 24 VDC | 40×260×200 mm | 1.05 kg |
| 1C31125G02 | Digital Input Module | 32 | 24 VDC | 40×260×200 mm | 1.05 kg |
Popular Models from Emerson / Ovation Family
| Model | Product Type | Application Platform | Dimensions (W×H×D) | Weight |
|---|---|---|---|---|
| 1C31110G03 | CPU Module | Ovation DCS | 50×260×200 mm | 1.2 kg |
| 1C31227G01 | Analog Input Module | Ovation DCS | 40×260×200 mm | 1.05 kg |
| 1C31113G02 | Network Interface Module | Ovation DCS | 50×260×200 mm | 1.15 kg |
| 1C31194G01 | Digital Output Module | Ovation DCS | 40×260×200 mm | 1.05 kg |
| 1C31150G01 | Power Supply Module | Ovation DCS | 75×260×200 mm | 1.8 kg |
| 1C31224G01 | HART Analog Input Module | Ovation DCS | 40×260×200 mm | 1.05 kg |
