Product Introduction
The OVATION 1X00046H01 Copper to Fiber Media Converter is designed to provide seamless conversion between copper-based Ethernet networks and fiber-optic networks. It allows long-distance data transmission while maintaining high reliability and immunity to electromagnetic interference. By bridging copper and fiber segments, it ensures stable communication in industrial automation, control systems, and critical infrastructure. This converter is particularly suited for Ovation DCS (Distributed Control System) environments where robust and stable connectivity is crucial.
Technical Specifications
| Parameter | Value |
|---|---|
| Model | OVATION 1X00046H01 Copper to Fiber Media Converter |
| Supported Standards | IEEE 802.3, IEEE 802.3u |
| Data Rate | 10/100 Mbps auto-negotiation |
| Copper Interface | RJ-45, 10/100Base-TX |
| Fiber Interface | SC/LC/ST (depending on configuration), 100Base-FX |
| Fiber Mode | Multi-mode or Single-mode |
| Transmission Distance | Multi-mode: up to 2 km, Single-mode: up to 20 km or more |
| Power Supply | 24 VDC typical |
| Operating Temperature | -10°C to +60°C |
| Humidity Range | 10% – 90% non-condensing |
| Dimensions (mm) | 120 × 80 × 30 mm |
| Weight (kg) | 0.45 kg |
Product Applications
-
Used in Ovation DCS networks for converting copper Ethernet to fiber optic links.
-
Suitable for industrial plants, power generation facilities, and water treatment systems where long-distance, noise-immune communication is required.
-
Enhances network reliability in control rooms, substations, and distributed nodes.
-
Provides secure and stable communication in environments exposed to electrical noise or harsh industrial conditions.
Product Advantages
-
Extended Distance Communication – Fiber connection enables data transmission across kilometers without signal degradation.
-
High Immunity to Interference – Resistant to electromagnetic and radio frequency interference, ensuring reliable data flow.
-
Plug-and-Play Setup – Supports auto-negotiation for speed and duplex mode, minimizing configuration effort.
-
Compact and Lightweight Design – Easy integration into control panels or DIN-rail installations.
-
Flexibility – Supports both multi-mode and single-mode fiber options depending on system requirements.
-
Compatibility – Fully compliant with Ovation DCS architecture and integrates seamlessly with existing control modules.
FAQ
Q1: What type of Ethernet speeds does the 1X00046H01 support?
A1: It supports 10 Mbps and 100 Mbps with auto-negotiation.
Q2: Can this media converter work with both single-mode and multi-mode fibers?
A2: Yes, it is available in versions that support both single-mode and multi-mode fibers.
Q3: Does it support full-duplex communication?
A3: Yes, it supports both half-duplex and full-duplex modes.
Q4: What is the maximum fiber transmission distance?
A4: For multi-mode fiber, up to 2 km; for single-mode fiber, up to 20 km or more depending on the fiber type.
Q5: What type of connectors are supported on the fiber side?
A5: Depending on the configuration, SC, LC, or ST connectors are supported.
Q6: How is the converter powered?
A6: It typically uses a 24 VDC power supply.
Q7: Is hot-swapping supported?
A7: Yes, the converter can be inserted or removed without shutting down the entire system.
Q8: What is the error detection or monitoring capability?
A8: It supports link fault pass-through and LED status indicators for diagnostics.
Q9: Can it be mounted on DIN rails?
A9: Yes, the design allows easy integration with DIN-rail mounting systems.
Q10: Is it compatible with redundant network setups?
A10: Yes, it can be used in redundant network topologies to enhance reliability.
