Product Introduction
The OVATION 1X00093G01 Ethernet Switch is a reliable industrial networking device designed specifically for process control and automation environments. It provides stable, high-speed communication between controllers, operator stations, and other automation devices. Engineered for demanding conditions, the switch ensures data integrity, low latency, and continuous system availability. Its integration into the Ovation Distributed Control System (DCS) allows seamless operation and easy maintenance in power generation and critical infrastructure.
Product Advantages
-
Industrial Reliability: Built to withstand harsh operating environments including electrical noise and temperature fluctuations.
-
High Performance: Supports fast Ethernet communication with low latency for time-critical applications.
-
Seamless Integration: Optimized for Ovation DCS networks, reducing configuration time and ensuring compatibility.
-
Scalable Networking: Provides multiple Ethernet ports to expand system communication links easily.
-
Advanced Diagnostics: Equipped with status LEDs and diagnostic functions for quick troubleshooting.
-
Redundancy Support: Allows network redundancy for uninterrupted operation in critical applications.
Technical Specifications
| Parameter | Description |
|---|---|
| Model | OVATION 1X00093G01 Ethernet Switch |
| Function | Industrial Ethernet switching for DCS |
| Communication Standard | IEEE 802.3, 802.3u (Fast Ethernet) |
| Transmission Speed | 10/100 Mbps auto-negotiation |
| Ports | 8 × RJ45 Fast Ethernet ports |
| Redundancy | Supported (Ring / Failover modes) |
| Power Supply | 24 VDC nominal |
| Operating Temperature | 0°C to +55°C |
| Storage Temperature | -20°C to +70°C |
| Humidity | 5% – 95% non-condensing |
| Dimensions | 150 × 120 × 45 mm |
| Weight | 1.2 kg |
| Mounting | DIN-rail / Panel mounting |
Product Applications
The OVATION 1X00093G01 Ethernet Switch is widely applied in critical automation and control systems, particularly in the power generation industry. It is used to interconnect controllers, engineering stations, and operator workstations within Ovation DCS. Beyond power plants, it is also suitable for water treatment facilities, oil & gas automation, and industrial manufacturing where network reliability and real-time communication are essential.
FAQ
Q1: What communication protocols are supported by the 1X00093G01 Ethernet Switch?
A1: It supports standard Ethernet protocols including IEEE 802.3 and 802.3u, ensuring compatibility with a wide range of devices.
Q2: Can this switch be integrated with third-party controllers outside of Ovation DCS?
A2: Yes, it can communicate with third-party devices as long as they use standard Ethernet protocols.
Q3: Does the switch support redundant power supply connections?
A3: It is designed to operate reliably with 24 VDC power input and can be used with redundant DC power systems for higher availability.
Q4: How does the redundancy feature work in this switch?
A4: The switch supports ring and failover redundancy modes, allowing communication to continue even if one link fails.
Q5: What is the maximum number of devices that can be connected?
A5: It offers 8 Ethernet ports, so up to 8 direct connections are possible, with expansion available using additional switches.
Q6: Is Quality of Service (QoS) supported for prioritizing control traffic?
A6: Yes, the switch can prioritize traffic to ensure that time-critical control data is transmitted with minimal delay.
Q7: What diagnostic features are available for maintenance?
A7: The switch includes LED indicators for link, speed, and activity, along with error detection for easier troubleshooting.
Q8: Can VLANs be configured on this switch?
A8: Basic VLAN functionality is supported, allowing segmentation of network traffic within the control system.
Q9: What type of cabling is recommended for this switch?
A9: It supports standard Category 5e or higher twisted-pair cables for Ethernet connections.
Q10: Is the switch firmware upgradeable in the field?
A10: Yes, firmware updates can be applied to maintain compatibility and add enhanced features.
