Ovation 1X00163H02 Power Supply Module

Product Introduction

The Ovation 1X00163H02 Power Supply Module is an industrial-grade power conversion unit specifically designed for Emerson Ovation Distributed Control Systems (DCS). It provides stable and efficient DC power to Ovation controllers, I/O modules, and critical system peripherals. Engineered for high reliability and continuous operation, this module ensures uninterrupted power delivery even under fluctuating input conditions. Its rugged design, combined with advanced filtering and protection circuits, makes it suitable for demanding applications such as power generation, water treatment facilities, and process automation in oil, gas, and chemical industries. The 1X00163H02 integrates seamlessly into existing Ovation racks and supports hot-swapping, reducing system downtime during maintenance.

Product Specifications

Applications

• Power Generation – Provides steady 24 VDC power for turbines, generators, and plant control systems.

• Water and Wastewater Treatment – Supports continuous monitoring and control of pumps, valves, and sensors.

• Petrochemical Plants – Powers critical process control modules and safety instrumentation.

• Industrial Automation – Supplies clean power to PLCs, controllers, and industrial networking equipment.

• Renewable Energy Systems – Delivers reliable DC power for solar and wind energy control stations.

• Redundant Power Architectures – Designed to operate in parallel configurations for uninterrupted service.

Advantages

• High Efficiency – Achieves up to 90% conversion efficiency, reducing heat and energy loss.

• Comprehensive Protection – Built-in over-voltage, over-current, and short-circuit safeguards enhance system safety.

• Hot-Swap Capability – Enables module replacement without powering down the system, minimizing downtime.

• Robust Design – Withstands harsh industrial environments with wide temperature and humidity tolerances.

• Low Noise Output – Maintains <50 mV ripple, ensuring clean power for sensitive electronic circuits.

• Seamless Integration – Designed for direct installation in Ovation control racks without modification.

FAQ

1. What is the input voltage range supported by the 1X00163H02 module?
   It accepts a wide AC input range from 85 to 264 volts at 47 to 63 hertz, accommodating global power standards.

2. What is the regulated DC output provided by this module?
   The module delivers a stable 24 VDC output with tight voltage regulation to protect connected equipment.

3. How much continuous current can the power supply handle?
   It can provide up to 10 amperes of continuous current, supporting multiple Ovation components simultaneously.

4. Is the module hot-swappable during live operation?
   Yes, it can be inserted or removed without shutting down the Ovation system, allowing for maintenance without process interruption.

5. What protection mechanisms are integrated into the design?
   The module includes over-voltage, over-current, and short-circuit protection to ensure safety and equipment longevity.

6. How efficient is the power conversion process?
   The 1X00163H02 achieves at least 90% efficiency at full load, reducing energy loss and operating costs.

7. Does it require forced-air cooling?
   No. It is designed for natural convection cooling, which simplifies installation and reduces mechanical wear.

8. What is the acceptable operating temperature range?
   It performs reliably from 0 °C to +60 °C, suitable for most industrial control environments.

9. How is output ripple and noise managed?
   Advanced filtering circuitry keeps ripple below 50 mV peak-to-peak, ensuring stable and clean power output.

10. Can it be used in redundant power configurations?
    Yes, it supports parallel operation with another power module for redundancy and enhanced reliability.
