The Ovation 1X00416H04 Power Supply is a reliable DC power module designed to provide stable and regulated power for Ovation™ distributed control systems. This module ensures continuous operation of controllers, I/O modules, and communication interfaces in demanding industrial environments. Engineered for high efficiency and robust protection, the 1X00416H04 is ideal for power generation, oil & gas, water/wastewater treatment, and industrial automation applications where uninterrupted system operation is critical.
Product Parameters
| Parameter | Specification |
|---|---|
| Model Number | 1X00416H04 |
| Product Type | DC Power Supply Module |
| Output Voltage | 24 VDC nominal |
| Output Current | 8 A maximum |
| Input Voltage Range | 85–265 VAC, 50/60 Hz |
| Power Conversion Efficiency | ≥ 90 % |
| Voltage Regulation | ±2 % typical |
| Ripple & Noise | <50 mV peak-to-peak |
| Protections | Overvoltage, overload, short-circuit, and thermal protection |
| Communication Interface | Ovation™ redundant I/O bus |
| Operating Temperature | –20 °C to +60 °C |
| Storage Temperature | –40 °C to +85 °C |
| Relative Humidity | 5–95 % non-condensing |
| Dimensions | 130 × 50 × 160 mm |
| Weight | 0.6 kg |
| Certifications | CE, UL, CSA, ATEX Zone 2 |
Applications
-
Distributed Control Systems – Supplies reliable DC power to Ovation I/O and controller modules.
-
Power Generation – Supports turbine, boiler, and auxiliary control modules with stable power.
-
Oil & Gas Industry – Powers control and safety systems in harsh industrial environments.
-
Water & Wastewater Treatment – Provides continuous power for automation and monitoring equipment.
-
Industrial Automation – Powers sensors, actuators, and process controllers in manufacturing systems.
-
Building Automation – Suitable for Ovation modules used in HVAC, fire protection, and energy monitoring systems.
Advantages
-
Stable DC Output – Maintains 24 VDC with ±2 % regulation under varying loads.
-
Adequate Output Capacity – Supports up to 8 A to power multiple modules simultaneously.
-
High Efficiency – ≥90 % conversion efficiency minimizes heat generation and energy consumption.
-
Robust Protection Features – Includes overvoltage, overload, short-circuit, and thermal protection to safeguard connected devices.
-
Wide Input Voltage Range – Compatible with 85–265 VAC, allowing for global deployment.
-
Redundant Bus Support – Integrates seamlessly with Ovation redundant I/O bus for high availability.
-
Hot-Swappable – Can be replaced without interrupting system operation.
-
Certified for Hazardous Locations – CE, UL, CSA, and ATEX Zone 2 certifications allow deployment in industrial environments.
FAQ
-
What is the nominal output voltage of the 1X00416H04?
The module provides a regulated 24 VDC output suitable for powering Ovation controllers and I/O modules. -
What is the maximum output current?
It can supply up to 8 A to connected Ovation system modules. -
Which AC input voltage range does it support?
The module operates reliably with 85–265 VAC at 50/60 Hz. -
Does it offer protection against electrical faults?
Yes, it includes overvoltage, overload, short-circuit, and thermal protection features. -
Can it operate in extreme temperature and humidity conditions?
Yes, it is rated for –20 °C to +60 °C and 5–95 % non-condensing humidity. -
Is it compatible with redundant Ovation I/O buses?
Yes, it supports seamless integration with Ovation redundant buses. -
What is the efficiency of this power supply module?
The module operates at ≥90 % efficiency, reducing energy loss and heat. -
Can it be replaced without shutting down the system?
Yes, it is hot-swappable to minimize downtime during maintenance. -
Is the 1X00416H04 suitable for hazardous areas?
Yes, it complies with CE, UL, CSA, and ATEX Zone 2 certifications. -
Which Ovation components can it power?
It provides power to controllers, discrete and analog I/O modules, and communication interface modules.
