Product Overview
The Ovation 5A26458G05 Relay Output Base is a critical component of the Ovation distributed control system (DCS), designed to provide secure and reliable interfacing for relay output modules. It serves as the mounting base for relay output functions, ensuring proper electrical connections, simplified installation, and robust system performance in demanding industrial applications.
Key Features
-
Dedicated base for Ovation relay output modules
-
Provides reliable electrical connectivity and stable operation
-
Supports direct wiring to field devices
-
Simplifies installation, maintenance, and replacement of modules
-
Rugged and durable design for industrial environments
-
Seamless integration with Ovation DCS architecture
-
Suitable for a wide range of process automation applications
Technical Specifications
| Item | Specification |
|---|---|
| Model Number | 5A26458G05 |
| Type | Relay Output Base |
| System Compatibility | Ovation DCS |
| Supported Modules | Ovation relay output modules |
| Electrical Interface | Direct relay channel connections |
| Mounting | Panel or rack mount |
| Operating Temperature | 0 °C to +60 °C |
| Storage Temperature | -40 °C to +85 °C |
| Humidity | 5–95% non-condensing |
| Dimensions | 150 × 80 × 30 mm |
| Weight | 0.35 kg |
| Compliance | CE, UL, RoHS |
Industry Applications
-
Power Generation – turbine, generator, and auxiliary equipment relay control
-
Oil & Gas – relay interfacing for compressors, pumps, and safety devices
-
Chemical & Petrochemical – control of actuators, solenoids, and alarms
-
Manufacturing – relay output interfacing for machinery and automation
-
Water & Wastewater – motor and pump relay control systems
Advantages
-
Provides a stable and secure base for relay output modules
-
Simplifies wiring and reduces installation time
-
Ensures reliable relay operation for field devices
-
Designed for easy maintenance and quick module replacement
-
Rugged construction suitable for harsh industrial conditions
-
Seamless integration with Ovation control systems
-
Enhances overall system reliability and safety
Frequently Asked Questions (FAQ)
Q1: What is the function of the 5A26458G05?
It serves as a mounting base for Ovation relay output modules, providing electrical connections to field devices.
Q2: Which control system is it designed for?
It is designed for Ovation distributed control systems.
Q3: What type of field devices can be connected?
Devices such as actuators, alarms, solenoids, and contactors.
Q4: Does it support direct wiring?
Yes, it allows direct wiring to field devices.
Q5: What is the operating temperature range?
0 °C to +60 °C.
Q6: How is it mounted?
It can be panel or rack mounted.
Q7: Is it suitable for harsh environments?
Yes, it is designed with industrial-grade ruggedness.
Q8: What are the dimensions?
Approx. 150 mm × 80 mm × 30 mm.
Q9: What is its weight?
Approx. 0.35 kg.
Q10: Which industries commonly use it?
Power Generation, Oil & Gas, Chemical, Manufacturing, and Water & Wastewater.
