Product Overview
The Ovation 5X00241G04 Digital Input Module is designed to provide reliable acquisition of discrete input signals within Emerson’s Ovation distributed control system (DCS). It monitors the on/off status of field devices such as switches, relays, sensors, and interlocks, ensuring accurate real-time process control. With its robust design, diagnostic features, and seamless integration, this module is ideal for use in demanding industrial automation environments.
Key Features
-
High-density digital input capability
-
Monitors on/off status of field devices
-
Fast response time for real-time control applications
-
Electrical isolation between channels for safety
-
Built-in diagnostic and fault detection features
-
Hot-swappable design for minimized downtime
-
Seamless integration with Ovation DCS architecture
Technical Specifications
| Item | Specification |
|---|---|
| Model Number | 5X00241G04 |
| Series | Ovation |
| Type | Digital Input Module |
| Dimensions | 260 × 45 × 185 mm |
| Weight | 1.3 kg |
| Channels | 16 or 32 digital input channels (depending on config) |
| Input Voltage Levels | 24 VDC, 48 VDC, or 125 VDC (model dependent) |
| Input Type | Dry contact or voltage input |
| Isolation | Channel-to-channel and channel-to-system isolation |
| Response Time | <5 ms typical |
| Diagnostics | Input status monitoring and fault detection |
| Communication | Via Ovation I/O backplane |
| Operating Temperature | 0 °C to +60 °C |
| Storage Temperature | -20 °C to +85 °C |
| Humidity | 5% to 95% non-condensing |
| Compliance | CE, UL, RoHS |
Industry Applications
-
Power Generation – monitoring turbine status, breakers, and interlocks
-
Oil & Gas – compressor and pipeline equipment status monitoring
-
Petrochemical – process safety and equipment monitoring
-
Water & Wastewater – pump and motor control inputs
-
Industrial Manufacturing – machine and safety system monitoring
Advantages
-
High-density digital input design reduces module count
-
Reliable detection of on/off device status
-
Built-in diagnostics improve system reliability
-
Hot-swappable for minimal downtime during maintenance
-
Rugged construction suitable for harsh environments
Frequently Asked Questions (FAQ)
Q1: What is the main function of the 5X00241G04 module?
It monitors discrete on/off signals from field devices such as relays, sensors, and switches.
Q2: How many channels does it support?
It supports either 16 or 32 digital input channels, depending on the configuration.
Q3: What input voltage levels are supported?
It supports 24 VDC, 48 VDC, or 125 VDC (model dependent).
Q4: Does it support isolation?
Yes, it provides both channel-to-channel and channel-to-system isolation.
Q5: What is the typical response time?
Less than 5 ms.
Q6: What are the dimensions of the module?
260 mm × 45 mm × 185 mm.
Q7: What is the weight of the module?
1.3 kg.
Q8: Can the module be hot-swapped?
Yes, it is hot-swappable to minimize system downtime.
Q9: What compliance standards does it meet?
It complies with CE, UL, and RoHS standards.
Q10: Which industries commonly use this module?
It is widely used in power generation, petrochemical, oil & gas, water treatment, and manufacturing.
