Ovation 5X00261G01 Control Card

Product Introduction

The Ovation 5X00261G01 Control Card is a vital component within the Ovation Distributed Control System (DCS), specifically designed to manage core control tasks and data handling functions. It operates as an intelligent interface between the controller module and the connected I/O subsystems, executing control strategies, signal conditioning, and system communications.

The 5X00261G01 enhances the processing capacity of the DCS by managing complex control loops and providing deterministic response times. Its rugged industrial design, combined with built-in fault diagnostics and redundancy support, ensures uninterrupted process control in mission-critical environments such as power generation, water treatment, petrochemical plants, and large-scale industrial automation systems.

Product Specifications

Applications

The 5X00261G01 Control Card is widely deployed in automation systems requiring fast, reliable, and redundant process control:

• Power Generation Plants – Manages turbine, boiler, and balance-of-plant control loops.

• Water & Wastewater Treatment – Controls filtration, pumping, and chemical dosing processes.

• Oil & Gas Industry – Provides stable control for refining, pipeline management, and compressor stations.

• Petrochemical Industry – Executes control strategies for reactors, distillation units, and safety interlocks.

• Industrial Manufacturing – Handles logic and continuous control in production lines.

• Renewable Energy – Supports wind, solar, and hydroelectric plant process automation.

Advantages

The Ovation 5X00261G01 provides a range of advantages to system integrators and operators:

• Deterministic Control – Guarantees real-time response for mission-critical applications.

• Scalable Architecture – Easily integrates additional cards for system expansion.

• Fault-Tolerant Operation – Redundancy support minimizes downtime in case of hardware failure.

• Enhanced Diagnostics – Onboard monitoring and self-tests simplify maintenance.

• High Compatibility – Fully compatible with Ovation racks and backplane communications.

• Robust Reliability – Designed to withstand industrial operating environments.

• Flexible Communication – Supports multiple interfaces for easy plant integration.

Frequently Asked Questions (FAQ)

1. How does the 5X00261G01 interface with the Ovation system?
   It communicates via the Ovation backplane and integrates with system controllers and I/O modules.

2. What is the typical processing response time of this control card?
   It supports deterministic execution with sub-millisecond cycle times.

3. Does the 5X00261G01 support redundant operation?
   Yes, it can be configured in dual redundant mode to ensure continuous system availability.

4. What type of memory is included in the card?
   It is equipped with 1 GB RAM for processing and 256 MB flash for firmware and configuration storage.

5. What protection mechanisms are built into the module?
   It includes over-current protection, watchdog timer monitoring, and automatic system reset.

6. Is the control card capable of handling both analog and digital I/O?
   Yes, it supports a wide range of digital and analog I/O modules within the Ovation system.

7. How is diagnostic information provided to operators?
   The card offers built-in self-tests, error logging, and LED indicators for quick status feedback.

8. Can the module be hot-swapped during operation?
   Yes, it is designed for hot-swappable replacement to minimize downtime.

9. Which communication protocols are supported?
   Standard interfaces include Ethernet and optional Modbus for plant integration.

10. Is this module backward-compatible with legacy Ovation racks?
    Yes, it is designed for backward compatibility, allowing smooth upgrades in older systems.
