Product Introduction
The Ovation 5X00490G09 System Power Module is a critical component of the Ovation Distributed Control System (DCS), designed to provide stable and reliable power distribution to controllers, I/O modules, and communication components within the system. This module ensures uninterrupted operation of control functions by maintaining a regulated power supply under demanding industrial environments.
It is engineered with built-in protection mechanisms, fault detection, and redundancy support to maximize uptime. The 5X00490G09 is widely adopted in industries where continuous power delivery is essential, such as power generation, water treatment, oil & gas, petrochemical, and process automation sectors.
Product Specifications
| Parameter | Specification |
|---|---|
| Model Number | 5X00490G09 |
| Module Type | System Power Module |
| Function | Provides regulated and distributed power for Ovation DCS components |
| Input Voltage | 24 VDC nominal |
| Output Voltage | 5 VDC, ±12 VDC regulated |
| Power Rating | 150 W continuous |
| Efficiency | ≥ 90% |
| Protection Features | Over-voltage, over-current, short-circuit protection |
| Redundancy Support | Yes, supports dual power module operation |
| Cooling | Passive convection with thermal monitoring |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Humidity | 5% to 95% non-condensing |
| Diagnostics | Built-in monitoring with LED status indicators |
| Communication | Status reporting via Ovation system backplane |
| Dimensions | 220 x 120 x 55 mm |
| Weight | 0.7 kg |
| Mounting | Rack-mounted in Ovation chassis |
| Certification | CE, UL listed, industrial-grade |
Applications
The Ovation 5X00490G09 System Power Module is widely deployed in automation environments that require uninterrupted and conditioned power supply for critical control equipment:
-
Power Generation Plants – Provides stable power to turbine and boiler control modules.
-
Water & Wastewater Treatment – Ensures consistent operation of controllers for pumps, valves, and chemical dosing systems.
-
Petrochemical Industry – Maintains reliable power to critical process controllers and safety systems.
-
Oil & Gas – Delivers regulated power for pipeline monitoring, refining processes, and compressor control.
-
Industrial Manufacturing – Keeps automation controllers and I/O running during continuous operations.
-
Renewable Energy Plants – Supports solar and wind plant controllers, maintaining grid stability and performance.
Advantages
The 5X00490G09 provides numerous technical and operational benefits:
-
Stable Power Distribution – Ensures consistent voltage levels across all connected Ovation modules.
-
High Efficiency – With ≥90% efficiency, it reduces power loss and operational costs.
-
Fault Protection – Built-in over-voltage, over-current, and short-circuit protection enhance safety.
-
Redundancy Ready – Can be paired with another power module for uninterrupted operation.
-
Industrial Grade Reliability – Designed for harsh environments with wide operating temperature tolerance.
-
Real-Time Diagnostics – Integrated LED and system feedback allow quick identification of power conditions.
-
Easy Integration – Fully compatible with Ovation racks and system backplane for seamless installation.
Frequently Asked Questions (FAQ)
-
What is the input voltage requirement for the 5X00490G09 System Power Module?
The module requires a nominal input of 24 VDC. -
Which output voltages does the module provide?
It provides regulated 5 VDC and ±12 VDC outputs for Ovation system components. -
Can the module operate in redundant configurations?
Yes, it supports dual-module redundancy to ensure uninterrupted power. -
What type of fault protection is built into the 5X00490G09?
It includes protection against over-voltage, over-current, and short-circuit conditions. -
Does the power module provide diagnostic feedback to the system?
Yes, it communicates status information via the Ovation system backplane. -
How is cooling managed within the module?
The module uses passive convection cooling with thermal monitoring for safe operation. -
What is the maximum continuous power rating of this module?
It is rated at 150 W continuous output power. -
Are LED indicators available for quick troubleshooting?
Yes, front-panel LEDs display operational and fault conditions in real time. -
Is the module hot-swappable within the Ovation rack?
Yes, it is designed to be hot-swappable, minimizing downtime during maintenance. -
Can this module be integrated with legacy Ovation chassis?
Yes, it maintains backward compatibility with earlier Ovation rack systems.
Related Ovation Series Models
| Model Number | Module Type | Description |
|---|---|---|
| 5X00490G01 | System Power Module | Base version with standard power output |
| 5X00490G03 | System Power Module | Enhanced diagnostics with extended protection |
| 5X00490G05 | System Power Module | High-capacity version for larger systems |
| 5X00490G07 | System Power Module | Redundant-ready configuration with advanced monitoring |
| 5X00490G08 | System Power Module | Compact variant for limited-space installations |
| 5X00490G10 | System Power Module | Next-generation module with improved efficiency |
Popular Ovation Models (Same Brand)
| Model Number | Module Type | Description |
|---|---|---|
| 5X00488G01 | I/O Module | Handles mixed analog and digital signals |
| 5X00489G02 | Communication Module | Provides Ethernet and Modbus connectivity |
| 5X00491G01 | Controller Module | Central CPU for Ovation DCS systems |
| 5X00492G02 | Signal Conditioning Module | Processes and scales analog inputs |
| 5X00493G01 | Safety Module | Provides critical interlock and shutdown functions |
| 5X00495G01 | Data Acquisition Module | High-speed process data collection |
