Product Overview
The Ovation 5X00594G01 Analog Input Module is a high-performance module designed for Emerson’s Ovation distributed control system (DCS). It provides accurate and reliable acquisition of analog signals from field instruments, such as transmitters and sensors, ensuring precise monitoring and control in critical industrial processes.
Key Features
-
High-resolution analog signal acquisition
-
Compatible with Emerson Ovation DCS systems
-
Supports multiple input ranges and signal types
-
Designed for stable and accurate measurement
-
Built-in protection against electrical noise and surges
-
Modular and compact design for ease of installation
-
Reliable performance in industrial environments
Technical Specifications
| Item | Specification |
|---|---|
| Model Number | 5X00594G01 |
| Type | Analog Input Module |
| System Compatibility | Emerson Ovation DCS |
| Input Channels | Multiple (typically 8–16, depending on configuration) |
| Input Signal Types | Current (mA), Voltage (V), and other standard analog signals |
| Resolution | High-resolution A/D conversion (typically 12–16 bit) |
| Isolation | Channel-to-channel and channel-to-system isolation |
| Protection | Input overvoltage and surge protection |
| Operating Temperature | 0 °C to +60 °C |
| Storage Temperature | -40 °C to +85 °C |
| Humidity | 5–95% non-condensing |
| Dimensions | 180 × 120 × 40 mm |
| Weight | 0.6 kg |
| Compliance | CE, UL, RoHS |
Industry Applications
-
Power Generation – monitoring turbine, boiler, and auxiliary analog signals
-
Oil & Gas – acquisition of analog signals from sensors in refineries and offshore platforms
-
Chemical & Petrochemical – monitoring process variables like flow, level, and temperature
-
Manufacturing – supports automation processes requiring accurate measurement
-
Water & Wastewater – monitoring pumps, valves, and treatment processes
Advantages
-
Provides precise and reliable analog input data for control systems
-
Supports a wide range of field signal types
-
Improves process accuracy and reliability
-
Designed for seamless integration with Ovation DCS
-
Robust protection enhances long-term module durability
-
Modular design allows easy installation and replacement
Frequently Asked Questions (FAQ)
Q1: What is the function of the 5X00594G01?
It acquires analog input signals from field devices and transmits them to the Ovation DCS.
Q2: Which control system is it compatible with?
It is specifically designed for Emerson Ovation DCS systems.
Q3: How many input channels does it support?
It typically supports multiple channels (commonly 8–16 depending on configuration).
Q4: What types of signals are supported?
Standard analog signals, including current (mA) and voltage (V).
Q5: What is the resolution of the module?
High-resolution conversion, typically 12–16 bits.
Q6: Does it provide channel isolation?
Yes, it supports channel-to-channel and channel-to-system isolation.
Q7: What protection features are included?
It includes surge and overvoltage protection.
Q8: What is the operating temperature range?
0 °C to +60 °C.
Q9: What are the dimensions?
Approx. 180 mm × 120 mm × 40 mm.
Q10: How much does it weigh?
Approx. 0.6 kg.
