Product Introduction
The OVATION 5X0070G05 16-Channel Analog Input Module is a high-performance input module designed for Emerson’s OVATION Distributed Control System (DCS). It is engineered to receive multiple analog signals simultaneously, convert them into a digital form, and provide precise, reliable data for critical industrial processes. This module is widely used in power generation, petrochemical plants, water treatment facilities, and other automation environments where accurate analog data acquisition is essential.
Technical Specifications
| Parameter | Description |
|---|---|
| Model | OVATION 5X0070G05 |
| Type | 16-Channel Analog Input Module |
| Number of Channels | 16 isolated analog inputs |
| Input Signal Range | Configurable for standard industrial ranges (0–10 V, ±10 V, 0–20 mA, 4–20 mA) |
| Resolution | 12-bit or higher |
| Sampling Rate | High-speed scanning for real-time applications |
| Isolation | Channel-to-channel and channel-to-ground isolation |
| Communication | OVATION I/O bus |
| Power Supply | 24 VDC nominal |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Dimensions | 175 × 125 × 35 mm |
| Weight | 0.45 kg |
| Mounting | Standard OVATION I/O chassis slot |
| Compatibility | Fully compatible with OVATION controllers and I/O subsystems |
Product Applications
-
Power Generation Plants: Monitoring turbine, boiler, and generator parameters.
-
Oil and Gas Industry: Acquiring pressure, flow, and temperature signals from field sensors.
-
Water and Wastewater Treatment: Recording pH, dissolved oxygen, and flow signals.
-
Petrochemical Plants: Supervising critical production parameters for process optimization.
-
Industrial Manufacturing: Ensuring real-time monitoring of production line equipment and systems.
Product Advantages
-
High Channel Density: 16 analog channels in one module, reducing the number of modules required.
-
Accuracy and Reliability: High-resolution A/D conversion for precise measurements.
-
Strong Isolation: Protects against signal interference and ensures measurement integrity.
-
Seamless Integration: Fully compatible with Emerson OVATION DCS, ensuring easy system expansion.
-
Compact and Robust Design: Space-saving and durable, suitable for harsh industrial conditions.
-
Flexible Signal Handling: Supports multiple industrial analog signal ranges.
FAQ
Q1: What types of analog signals can the OVATION 5X0070G05 accept?
A1: It supports standard voltage and current ranges such as 0–10 V, ±10 V, 0–20 mA, and 4–20 mA.
Q2: How many channels can be configured independently?
A2: All 16 channels can be independently configured for different signal types.
Q3: Does the module provide channel-to-channel isolation?
A3: Yes, it provides isolation between channels as well as from channel to ground.
Q4: What is the resolution of the input signals?
A4: The module provides at least 12-bit resolution for precise analog-to-digital conversion.
Q5: How does the module communicate with the OVATION controller?
A5: It communicates through the OVATION I/O bus interface.
Q6: Can it be hot-swapped without shutting down the system?
A6: Yes, the module is designed for hot-swapping in the OVATION I/O chassis.
Q7: What is the typical input impedance of the module?
A7: The input impedance is designed to match standard industrial sensors, typically in the range of 250–500 ohms for current inputs.
Q8: Is the module capable of filtering noise from analog signals?
A8: Yes, it includes configurable filtering mechanisms to minimize electrical noise.
Q9: Can this module operate in redundant configurations?
A9: Yes, it supports redundancy for critical applications when used with redundant controllers and I/O systems.
Q10: How does the module handle calibration?
A10: Calibration is software-configurable and can be performed remotely via the OVATION system.
