Product Overview
The Schneider Electric 140CPU43412U Unity Processor is a high-performance central processing unit designed for use with Schneider’s Modicon Quantum Series PLCs, offering advanced automation capabilities for complex control applications. Engineered for large-scale industrial processes, this CPU provides exceptional processing speed, extensive memory, integrated communication capabilities, and full support for Unity Pro programming software, ensuring seamless control and monitoring across a wide range of industries.
With its robust design, redundancy options, and high-speed data handling, the 140CPU43412U is ideal for mission-critical automation systems where reliability, flexibility, and real-time processing are essential. It offers embedded Ethernet and Modbus ports, making system integration, remote diagnostics, and data exchange more efficient.
Key Features
-
High-speed Unity processor for demanding automation tasks
-
Designed for Schneider Modicon Quantum PLC platform
-
Full compatibility with Unity Pro programming environment
-
Embedded Ethernet TCP/IP port for network connectivity
-
Integrated Modbus serial communication port
-
Large internal memory for complex control applications
-
Supports hot standby and redundancy configurations
-
High-speed processing for time-critical control loops
-
Robust construction for operation in harsh industrial environments
-
Extensive diagnostics and real-time system monitoring capabilities
-
Ideal for process control, manufacturing, and infrastructure automation
Technical Specifications
| Parameter | Description |
|---|---|
| Product Name | Schneider Electric Modicon Quantum Unity Processor |
| Model Number | 140CPU43412U |
| PLC Platform | Modicon Quantum Series |
| Processor Type | Unity Processor with 32-bit architecture |
| Clock Frequency | 100 MHz |
| Internal Memory | 1 MB for application code + 384 KB for data |
| User Application Capacity | 1 MB (expandable via memory cards) |
| Programming Software | Unity Pro, EcoStruxure Control Expert |
| Communication Ports | 1 x Ethernet 10/100 Mbps, 1 x Modbus Serial (RS-232/RS-485) |
| Redundancy Support | Yes, supports Hot Standby (HSBY) configuration |
| Data Handling Capacity | High-speed data exchange and deterministic processing |
| Diagnostics | Built-in diagnostics, system status LEDs |
| Operating Temperature Range | 0°C to +60°C |
| Storage Temperature Range | -40°C to +85°C |
| Humidity Resistance | 5% to 95% non-condensing |
| Power Consumption | 5 Watts (typical) |
| Dimensions | Package size: 45 x 155 x 310 mm |
| Weight | 0.607 kg |
| Certifications | CE, UL, CSA, ATEX (optional), RoHS compliant |
Product Advantages
-
High-Performance Processing: With a 100 MHz processor and large memory, the 140CPU43412U handles complex control logic with ease.
-
Unity Pro Integration: Fully compatible with Unity Pro software for intuitive programming, diagnostics, and system management.
-
Network Connectivity: Embedded Ethernet port facilitates real-time data exchange, system integration, and remote access.
-
Redundancy Support: Hot standby functionality ensures continuous operation and maximizes system uptime in critical applications.
-
Flexible Communication: Integrated Modbus port allows for connection with legacy and modern devices.
-
Industrial Durability: Robust construction designed to withstand demanding environments with wide temperature and humidity ranges.
-
Efficient Data Handling: Optimized for fast data processing, making it ideal for time-sensitive control operations.
-
System Diagnostics: Comprehensive LED indicators and diagnostic tools simplify maintenance and troubleshooting.
-
Global Compliance: Meets international standards for safety, electromagnetic compatibility, and environmental protection.
-
Long-Term Reliability: Designed for industrial environments where continuous operation and system stability are essential.
Industry Applications
The Schneider 140CPU43412U Unity Processor is suitable for advanced automation solutions across a variety of industries:
-
Power Generation and Distribution: Real-time control of power plant operations, substations, and energy management systems
-
Oil & Gas: Process automation, safety systems, and remote monitoring of drilling, refining, and pipeline operations
-
Water and Wastewater Treatment: Supervisory control of treatment plants, pump stations, and distribution networks
-
Manufacturing: Complex production line control, robotics, and material handling systems
-
Mining and Metals: Automation of crushers, conveyors, and mineral processing equipment
-
Chemical and Pharmaceutical Processing: Precision control for batch and continuous production systems
-
Food and Beverage: High-speed processing lines and quality control systems
-
Transportation and Infrastructure: Control systems for tunnels, airports, and intelligent transportation solutions
Frequently Asked Questions (FAQ)
Q1: What PLC platform is the 140CPU43412U compatible with?
It is designed for Schneider Electric’s Modicon Quantum Series PLC platform.
Q2: Does the CPU support Unity Pro software?
Yes, it is fully compatible with Unity Pro and EcoStruxure Control Expert programming environments.
Q3: What is the main advantage of Unity processors over traditional CPUs?
Unity processors offer higher performance, more memory, better diagnostics, and integrated communication options, making them ideal for complex applications.
Q4: Can the CPU be used in redundant configurations?
Yes, it supports Hot Standby (HSBY) redundancy, ensuring continuous operation in case of CPU failure.
Q5: What communication ports are included?
The CPU includes 1 Ethernet port (10/100 Mbps) and 1 Modbus serial port (RS-232/RS-485).
Q6: Is the 140CPU43412U suitable for harsh industrial environments?
Yes, it is designed to operate within a wide temperature and humidity range and features robust construction.
Q7: What is the memory capacity for user applications?
It provides 1 MB of application memory, with additional 384 KB for data, expandable via memory cards.
Q8: Is this processor certified for global use?
Yes, it complies with CE, UL, CSA, RoHS, and ATEX standards (ATEX for specific models).
Q9: How is system status monitored?
The processor has built-in diagnostics and status LEDs for monitoring system health and performance.
Q10: Can this processor be integrated with legacy Modicon Quantum systems?
Yes, it maintains backward compatibility with Modicon Quantum components and expands functionality with Unity Pro capabilities.
Recommended Related Models
| Model Number | Description |
|---|---|
| 140CPU65150 | High-End Unity Processor with Expanded Memory |
| 140CPU65160 | Premium Unity Processor with Maximum Performance |
| 140CPU53414B | Mid-Range Quantum Processor with Ethernet |
| 140CPU67260 | Redundant Processor for High-Availability Systems |
| 140CPU11303 | Entry-Level Processor for Basic Control Tasks |
| 140CPU65260 | High-Capacity Unity Processor with Redundancy Support |
Popular Schneider Electric Automation Products
| Model Number | Description |
|---|---|
| BMXP342020 | Modicon M340 Mid-Range Processor |
| TM241CEC24T | Modicon M241 Logic Controller with Ethernet |
| TSXPSY2600 | Quantum Series Power Supply |
| TSXP572634M | Premium Series Processor for Advanced Control |
| TSXP574823M | Electrically Independent Processor with High Performance |
| TSXDSY16T2 | Digital Output Module for Modicon PLC Systems |
