Product Overview
Schneider Electric 140MMB10400 is a high-performance Modbus Plus communication module, designed specifically for the Quantum automation platform. It provides a reliable and high-speed interface for Quantum PLCs to communicate with devices and other controllers over a Modbus Plus network. Known for its robustness, modularity, and industrial-grade design, the 140MMB10400 is typically used in large-scale industrial applications where deterministic and redundant communication is critical.
Product Features & Specifications
| Parameter | Value |
|---|---|
| Product Name | Modbus Plus Communication Module |
| Manufacturer | Schneider Electric |
| Product Code | 140MMB10400 |
| Series | Modicon Quantum |
| Network Type | Modbus Plus |
| Communication Port | 1 × Modbus Plus DB9 Connector |
| Baud Rate | 1 Mbps |
| Bus Length | Up to 450 meters (without repeaters) |
| Connector Type | 9-pin D-sub female |
| Isolation | Optical and galvanic isolation |
| Status Indicators | LED (for network and module status) |
| Diagnostics | Built-in self-test and network diagnostics |
| Power Consumption | 400 mA at 5 VDC |
| Mounting Type | Rack-mounted (Quantum backplane) |
| Operating Temperature | 0 to 60°C |
| Storage Temperature | -40 to 85°C |
| Humidity | 5% to 95% (non-condensing) |
| Certifications | CE, UL, CSA, ATEX |
| Dimensions | 102 x 32 x 152 mm |
| Weight | 0.18 kg |
Applications
The Schneider 140MMB10400 is widely used in industrial environments where high-speed and deterministic communication is required. Applications include:
-
Process Automation in oil & gas, chemical, and pharmaceutical sectors
-
Power Generation and Distribution systems
-
Water and Wastewater Treatment control systems
-
Heavy Manufacturing such as metal and pulp industries
-
Batch Control and continuous processing systems
-
Distributed SCADA Networks
Product Advantages
-
Reliable Communication: Offers consistent and redundant Modbus Plus networking with low latency.
-
Industrial-grade Build: Designed to perform in harsh industrial conditions with high EMC resistance.
-
Easy Integration: Seamlessly integrates with other Modicon Quantum modules and existing Modbus Plus systems.
-
Hot Swappable: Can be replaced or installed without shutting down the backplane power.
-
Status LEDs: Real-time status indicators provide quick diagnostics and reduce maintenance time.
-
Long Cable Runs: Supports long communication distances, up to 450 meters without repeaters.
Frequently Asked Questions (FAQ)
Q1: What is the function of the 140MMB10400 module?
A1: It enables Quantum PLCs to communicate over the Modbus Plus network with other controllers, HMIs, and field devices.
Q2: Is this module compatible with Modicon M340 or M580 series?
A2: No, the 140MMB10400 is specifically designed for the Modicon Quantum platform.
Q3: Can this module be used in redundant network configurations?
A3: Yes, it supports redundant Modbus Plus configurations to enhance network reliability.
Q4: What connector type does it use?
A4: It uses a 9-pin D-sub female connector for Modbus Plus interface.
Q5: Does the module support diagnostic functions?
A5: Yes, it includes built-in diagnostics and LED indicators for network and internal status.
Q6: What is the installation method for this module?
A6: It is rack-mounted on the Quantum backplane and can be installed or removed without interrupting the power.
Q7: What environments is this module certified for?
A7: It holds certifications for CE, UL, CSA, and ATEX environments.
Q8: How is it powered?
A8: It consumes 400 mA from the 5 VDC power supply provided by the Quantum backplane.
Q9: What is the typical application of this module?
A9: It is used in industrial control systems requiring Modbus Plus communication, such as SCADA, DCS, and automation cells.
Q10: How do I monitor the operational status?
A10: LED indicators on the front panel show the operational, error, and communication status in real time.
