Product Introduction
The Schneider Electric 140NOA61100 is a robust and reliable Terminal Block Module from the Modicon Quantum series. Designed primarily for use in industrial automation systems, this component serves as a passive interface module that facilitates the secure and efficient connection of field devices to the I/O modules of a Modicon Quantum PLC system.
This module plays a critical role in simplifying wiring, minimizing installation time, and reducing the chances of wiring errors in complex systems. Engineered to operate in challenging environments, the 140NOA61100 provides durable connectivity, high mechanical stability, and consistent performance—qualities that are essential in mission-critical control environments.
Technical Specifications
| Parameter | Value |
|---|---|
| Product Type | Terminal Block Module |
| Series | Modicon Quantum |
| Model Number | 140NOA61100 |
| Function | Interface between I/O modules and field wiring |
| Dimensions | 70 × 190 × 65 mm |
| Weight | 0.25 kg |
| Mounting Type | Panel / DIN Rail |
| Terminal Type | Screw clamp |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Relative Humidity | 5% to 95% non-condensing |
| Compliance Standards | CE, UL, CSA |
| Number of Terminals | 16 channels |
| RoHS Compliant | Yes |
Product Advantages
-
Simplified Field Wiring: Direct terminal access reduces the need for intermediary wiring, helping engineers streamline installation.
-
Mechanical Stability: The rugged enclosure and secure terminal design ensure vibration resistance and long operational life.
-
High Compatibility: Seamlessly integrates with Schneider Quantum I/O modules, maintaining system coherence and integrity.
-
Reduced Installation Errors: Organized terminal layout helps avoid miswiring and facilitates faster maintenance.
-
Scalable Integration: Suitable for expansion in modular PLC architectures, supporting future system upgrades.
-
Environmentally Hardened: Built to operate reliably in industrial conditions with high temperature and humidity ranges.
-
Certified Quality: Meets global industrial safety and performance standards, ensuring compliance and reliability.
Product Applications
The Schneider 140NOA61100 is widely used across industries such as:
-
Oil & Gas: For safe and reliable signal wiring in remote terminal units (RTUs) and process control nodes.
-
Power Generation: In DCS/SCADA systems for managing sensor and actuator signal interfaces.
-
Manufacturing Automation: Ensuring organized wiring in modular, large-scale production systems.
-
Water Treatment: For signal transmission between field sensors and PLCs in water purification plants.
-
Transportation Infrastructure: In systems requiring high-reliability wiring in rail or tunnel automation.
Frequently Asked Questions (FAQs)
Q1: What is the primary use of the 140NOA61100 module?
A1: It acts as a terminal block interface for securely wiring field devices to Quantum I/O modules.
Q2: Is it compatible with all Schneider Quantum PLCs?
A2: Yes, it’s designed specifically for Quantum series I/O modules and integrates seamlessly.
Q3: Can this module be used in high-vibration environments?
A3: Absolutely. Its rugged design and screw terminal connections make it suitable for such conditions.
Q4: How many field connections does the module support?
A4: The 140NOA61100 supports 16 terminal points for field wiring.
Q5: Does it support hot swapping?
A5: No, the module itself is passive and not designed for hot-swap functionality.
Q6: What is the recommended installation method?
A6: It can be DIN rail or panel mounted, depending on your control cabinet layout.
Q7: What certifications does this product hold?
A7: It holds CE, UL, and CSA certifications, ensuring compliance with international standards.
Q8: Is the terminal block RoHS compliant?
A8: Yes, it adheres to RoHS environmental compliance.
Q9: Can it be used outdoors?
A9: It is not rated for direct outdoor use unless housed in a weatherproof enclosure.
Q10: Does the module require software configuration?
A10: No, it’s a passive hardware component and requires no configuration.
Recommended Models (Same Series / Related)
-
Schneider 140NOA61110 – Terminal block with enhanced EMI shielding
-
Schneider 140NOE77101 – Ethernet TCP/IP communication module
-
Schneider 140DDI35300 – 32-point digital input module
-
Schneider 140DAO84000 – 16-channel analog output module
-
Schneider 140CPU65160 – High-performance Quantum CPU
-
Schneider 140CPS11420 – Redundant power supply module
Popular Schneider Models (With Specs)
| Model Number | Function | Dimensions (mm) | Weight (kg) | Voltage |
|---|---|---|---|---|
| 140CPU65160 | Quantum CPU | 135 × 185 × 75 | 0.55 | 5V DC (internal) |
| 140NOE77101 | Ethernet Communication Module | 70 × 190 × 65 | 0.3 | 5V DC |
| 140DDI35300 | Digital Input Module | 135 × 185 × 75 | 0.4 | 24V DC |
| 140DAI55300 | Analog Input Module | 135 × 185 × 75 | 0.45 | 24V DC |
| 140DAO84000 | Analog Output Module | 135 × 185 × 75 | 0.5 | 24V DC |
| 140ACI04000 | Current Input Module | 135 × 185 × 75 | 0.48 | 24V DC |
| 140CPS11420 | Redundant Power Supply | 135 × 190 × 90 | 0.7 | 115/230V AC |
| 140XBP00600 | Backplane, 6-slot | 265 × 175 × 70 | 1.2 | Passive |
