Product Introduction
The Schneider 140XTS00100 Terminal Block is a robust and reliable component designed specifically for use within Schneider Electric’s Modicon Quantum automation platform. This terminal block plays a critical role in facilitating secure and organized electrical connections between I/O modules and field devices. Built with precision and industrial durability in mind, it ensures excellent contact reliability, ease of maintenance, and efficient wiring solutions in demanding automation environments.
As an integral part of the Quantum automation system, the 140XTS00100 is ideal for applications requiring high-density wiring, optimal signal clarity, and fast installation. This terminal block not only simplifies connections but also enhances the safety and clarity of the system layout by supporting consistent wire management and labeling practices.
Product Specifications
| Parameter | Value |
|---|---|
| Product Name | Schneider 140XTS00100 Terminal Block |
| Manufacturer | Schneider Electric |
| Product Series | Modicon Quantum |
| Type | Terminal Block |
| Compatible Modules | 140 series I/O modules |
| Material | Polyamide body, copper alloy contacts |
| Mounting Type | Rail Mount (DIN Rail) |
| Number of Terminals | 32 |
| Operating Temperature Range | -25°C to +70°C |
| Storage Temperature Range | -40°C to +85°C |
| Insulation Resistance | ≥ 100 MΩ |
| Dielectric Strength | 2000 V AC |
| Connection Technology | Screw clamp terminals |
| Color | Grey |
| Dimensions (H x W x D) | 50 x 250 x 50 mm |
| Weight | 0.159 kg |
| Certification | CE, UL, CSA |
| Environmental Protection | IP20 |
| RoHS Compliance | Yes |
Product Applications
The Schneider 140XTS00100 Terminal Block is widely used in various industrial automation applications, particularly within systems that utilize the Modicon Quantum PLC platform. Common applications include:
-
Manufacturing Automation: Ensures safe and efficient wiring in process automation systems.
-
Oil & Gas: Facilitates signal and power transmission in hazardous and high-vibration environments.
-
Energy & Utilities: Used in power plant and substation automation for reliable I/O connections.
-
Water Treatment: Supports signal integrity in SCADA-based plant operations.
-
Transportation: Enables organized terminal wiring in control cabinets for rail and metro automation systems.
-
Chemical Processing: Provides secure terminal connections in chemically volatile environments.
Product Advantages
-
Seamless Compatibility: Designed specifically for Modicon Quantum I/O modules, ensuring a perfect fit.
-
Durability: Constructed from industrial-grade materials for long-term performance under harsh conditions.
-
Easy Installation: Rail-mountable with intuitive terminal arrangement for efficient installation and maintenance.
-
High Safety Standards: Offers excellent dielectric strength and insulation resistance, meeting global safety regulations.
-
Optimized Wiring: Supports clean and organized cable management, reducing human error in wiring operations.
-
Reliability: Delivers stable electrical connections with minimal signal loss, even in high-vibration environments.
-
Space Efficiency: Compact form factor enables high-density wiring in control cabinets.
Frequently Asked Questions (FAQ)
-
Q: What is the 140XTS00100 Terminal Block used for?
A: It is used to connect field I/O signals to the corresponding Quantum I/O modules safely and efficiently. -
Q: Is this terminal block compatible with all Modicon Quantum I/O modules?
A: Yes, it is designed to work seamlessly with the 140 series I/O modules within the Quantum platform. -
Q: How many terminals does the 140XTS00100 have?
A: It comes with 32 terminal points for input/output wiring. -
Q: What type of mounting is supported?
A: It supports DIN rail mounting, allowing for easy installation in control panels. -
Q: What is the operating temperature range of the terminal block?
A: The operating range is from -25°C to +70°C. -
Q: Is the terminal block RoHS compliant?
A: Yes, it is fully RoHS compliant, meeting environmental standards. -
Q: Can this be used in high-vibration environments like oil rigs?
A: Absolutely. It is built with durable components that perform reliably in such settings. -
Q: What kind of connection technology does it use?
A: It uses screw clamp terminal connections for secure wire fastening. -
Q: What is the IP rating of the 140XTS00100?
A: It has an IP20 rating, suitable for cabinet-enclosed installations. -
Q: Are there any specific certifications for this product?
A: Yes, it is certified under CE, UL, and CSA standards.
Related Models from the Same Series
| Model Number | Description | Compatibility |
|---|---|---|
| 140XTS00200 | Terminal block with 64 terminals | Modicon Quantum I/O |
| 140XTS01200 | Isolated terminal block for analog modules | 140 series analog I/O |
| 140XTS00300 | Terminal block with test points | Digital I/O diagnostics |
| 140XTS02100 | Terminal block for redundant modules | Redundant systems |
| 140XTS02000 | Terminal block with integrated fuses | Protection applications |
| 140XTS01000 | Compact terminal block, 16-point | Space-constrained panels |
Popular Models from the Same Brand (Schneider Electric)
| Model Number | Product Description | Function |
|---|---|---|
| 140CPU65160 | Quantum CPU module, high-performance | Control and processing |
| BMXDDO1602 | Discrete Output Module, 16 channels | Digital output control |
| BMEP583040 | Modicon M580 PAC Processor | Industrial process automation |
| TSXPSY2600 | Power Supply Module, 24V | Power for PLC systems |
| 140NOE77101 | Ethernet Module for Quantum PLC | Networking and communication |
| BMXCPS4002 | Power Supply for Modicon X80 I/O | Modular I/O power management |
