Schneider 170AAI14000 Distributed Analog Input Base

Product Introduction

The Schneider Electric 170AAI14000 is a distributed analog input module belonging to the Modicon Momentum I/O family. Designed for precision and durability, this module is engineered to acquire and transmit analog process signals within a distributed control architecture. It features eight isolated analog input channels, which allow for simultaneous high-accuracy measurement of field signals in industrial environments.

The 170AAI14000 supports multiple input ranges (0–10 V, 4–20 mA, and other common ranges), ensuring compatibility with a wide array of transmitters and sensors. With optical isolation between channels, it guarantees signal integrity even in electrically noisy conditions. The module is used in combination with Momentum I/O bases and network adapters, forming a compact, modular automation solution suitable for demanding applications.

Whether used in standalone applications or integrated within large-scale automation networks, the 170AAI14000 delivers robust performance, long service life, and easy installation.

Technical Specifications

Applications

The 170AAI14000 is extensively used in automation systems requiring the collection and processing of analog signals from field instrumentation. Its primary application sectors include:

• Water and wastewater treatment: Monitoring flow, pressure, pH, and level using 4–20 mA sensors.

• Building automation systems: Reading temperature and environmental sensors in HVAC control loops.

• Process industries: Capturing analog input signals for process variables like temperature, pressure, and humidity.

• Energy management: Real-time analog signal acquisition from power meters and transducers.

• Oil and gas: Data collection from analog transmitters in pipelines and refineries.

• Pharmaceutical and food sectors: Integration into cleanroom and batch process controls.

Product Advantages

• Eight Isolated Channels: Each analog input is individually isolated, protecting the system from electrical interference and cross-talk.

• Multiple Input Ranges: Supports both current and voltage inputs for flexibility in sensor types.

• High Signal Integrity: Optical isolation ensures accurate signal transmission even in high-noise environments.

• Compact & Modular: Fits into standard Momentum bases; ideal for distributed architecture.

• Easy Integration: Seamlessly compatible with Momentum processors and network adapters.

• Diagnostic Features: Built-in LEDs for fast troubleshooting and channel status indication.

• Industrial Durability: Engineered for tough environments with broad operating temperature and certified reliability.

Frequently Asked Questions (FAQ)

1. What input ranges are supported by the 170AAI14000 module?
   It supports multiple ranges including 0–10 V, 0–5 V, 1–5 V, 0–20 mA, and 4–20 mA.

2. Are the analog input channels isolated?
   Yes, all eight channels feature optical isolation for noise immunity and system protection.

3. What kind of resolution does this module provide?
   It offers a 12-bit resolution, which provides a fine granularity for analog signal conversion.

4. Can I use both voltage and current inputs on different channels?
   Yes, each channel can be independently configured for either voltage or current input.

5. How is the module powered?
   The module draws 5 V DC power directly from the I/O base through the Momentum backplane.

6. Can this module be hot-swapped?
   No, the module should be powered down or taken offline before replacement to ensure system safety.

7. Is this module compatible with Unity Pro software?
   Yes, it can be configured and managed using Unity Pro or Concept programming environments.

8. What is the typical installation method for this module?
   It can be DIN-rail mounted or panel-mounted as part of a Momentum I/O configuration.

9. Does the 170AAI14000 offer onboard diagnostics?
   Yes, it includes channel-specific LED indicators to assist in diagnostics and troubleshooting.

10. Can I use this module in remote I/O configurations?
    Yes, with the appropriate Momentum network adapters (e.g., Ethernet, Modbus, FIPIO), it can operate in distributed I/O applications.
