Schneider 490NAE91100 Main Bus Junction Box

Product Introduction

The Schneider 490NAE91100 Main Bus Junction Box is a robust electrical distribution component designed to facilitate safe and efficient connection and distribution of power within industrial and commercial electrical systems. Serving as a central hub for main bus connections, this junction box allows multiple circuits to be interconnected while maintaining high safety standards and minimizing electrical losses. It is engineered to handle high-current applications, providing reliable performance under demanding operating conditions. The design ensures compliance with international electrical standards, offering secure and organized wiring for large-scale electrical installations.

Product Parameters

Applications

• Industrial Plants – Centralized distribution of electrical power to multiple machinery and equipment.

• Commercial Buildings – Power distribution for large HVAC, lighting, and elevator systems.

• Renewable Energy Systems – Integration into solar and wind energy plants to manage high-current bus connections.

• Data Centers – Reliable power routing for server racks and cooling systems.

• Marine & Offshore Platforms – High-current distribution in challenging and vibration-prone environments.

• Manufacturing Facilities – Safely connects multiple production line circuits to the main bus.

Advantages

• High Current Capacity – Supports up to 400 A, suitable for heavy industrial and commercial loads.

• Short-Circuit Protection – Rated for 35 kA, ensuring safety under fault conditions.

• Durable Construction – Powder-coated steel enclosure protects against corrosion and mechanical impacts.

• Flexible Configuration – Multiple outgoing feeders allow easy integration into complex electrical networks.

• Standards Compliance – Meets IEC 61439 and UL 508A standards for safety and performance.

• Easy Installation – Wall or panel mountable with organized terminal layout for streamlined wiring.

• Maintenance Friendly – Removable covers and accessible terminals facilitate inspection and servicing.

FAQ

1. What is the maximum voltage the junction box can handle?
   The 490NAE91100 is rated for up to 600 V AC, suitable for industrial and commercial applications.

2. What is the rated current for this junction box?
   The main bus can carry up to 400 A continuously.

3. How many outgoing feeders can be connected?
   The junction box can accommodate 6–12 outgoing feeders depending on the configuration.

4. What short-circuit current is the box rated for?
   It is rated to withstand a short-circuit current of up to 35 kA.

5. What type of mounting is supported?
   The box supports both wall mounting and panel mounting for flexibility.

6. What standards does this junction box comply with?
   It complies with IEC 61439 and UL 508A standards for industrial electrical panels.

7. What materials are used in the construction of the box?
   The enclosure is made of steel with a powder-coated finish for durability and corrosion resistance.

8. Can the box be used in outdoor or harsh environments?
   It is designed primarily for indoor use (NEMA 1 / IP20); additional enclosures are recommended for outdoor applications.

9. How is wiring organized inside the junction box?
   Terminals are clearly labeled and arranged to allow organized, efficient, and safe wiring connections.

10. What is the operating temperature range for the junction box?
    It can operate reliably in temperatures from –25 °C to +60 °C.
