Product Introduction
The Schneider ABE7S16E2M0 is a solid-state output relay base designed for efficient signal transmission in industrial automation applications. As part of the Schneider Electric ABE7 series, this module serves as an interface between PLC output modules and field actuators, providing enhanced electrical isolation and reliable switching performance.
With 16 output channels, DIN rail compatibility, and a compact yet durable design, this relay base is ideal for applications requiring high-speed and frequent switching. The solid-state output technology ensures longer lifespan, higher reliability, and better resistance to wear compared to traditional electromechanical relays.
Product Specifications
| Parameter | Specification |
|---|---|
| Model Number | ABE7S16E2M0 |
| Product Type | Solid-State Output Relay Base |
| Number of Outputs | 16 channels |
| Output Type | Solid-state relay |
| Voltage Rating | 24V DC |
| Current Rating | 0.5A per channel |
| Response Time | Fast switching with low latency |
| Connection Type | Soldering terminals |
| Isolation Voltage | 2500V between input and output |
| Mounting Type | DIN Rail or Panel Mount |
| Operating Temperature | -25°C to 70°C |
| Storage Temperature | -40°C to 85°C |
| Humidity | 5% to 95% (non-condensing) |
| Dimensions | 206 x 71 x 77 mm |
| Weight | 0.407 kg |
| Protection Rating | IP20 |
Applications
The Schneider ABE7S16E2M0 is widely used in various industrial automation applications, including:
-
Manufacturing Automation – Controls actuators, solenoids, and motors in factory automation.
-
Process Control Systems – Provides high-speed signal switching for process industries.
-
Material Handling Equipment – Used in conveyor belt systems and robotic arms.
-
Power Plants – Manages switching in power distribution and generation.
-
Food & Beverage Industry – Ensures precision control in food processing lines.
-
Building Automation – Helps in HVAC and lighting control systems.
Product Advantages
-
High-Speed Switching – Solid-state technology allows ultra-fast switching with minimal delay.
-
Long Lifespan – No moving parts mean reduced wear and tear compared to electromechanical relays.
-
Compact & Lightweight – Ideal for space-constrained control panels.
-
High Electrical Isolation – 2500V isolation ensures better protection against electrical surges.
-
Efficient Power Management – Low power consumption enhances energy efficiency.
-
DIN Rail Mountable – Provides flexible mounting options for easy integration.
-
Reliable Performance – Works under extreme industrial conditions with high temperature tolerance.
-
Reduced Maintenance – Solid-state design eliminates contact degradation issues.
-
Secure Soldering Terminals – Ensures strong and reliable electrical connections.
-
Versatile Application – Suitable for PLC systems, SCADA, and industrial automation setups.
