Product Introduction
The Schneider BMEH586040 Redundant Processor Module is part of the Modicon M580 series, which includes Ethernet-native Programmable Automation Controllers (PACs) and safety PLC solutions. This processor module is designed for high-availability control architectures and supports redundancy for medium to large process automation applications.
The module integrates multiple Ethernet communication interfaces, enabling real-time data exchange, device connectivity, and system synchronization. It supports a single local rack configuration while allowing extensive remote I/O expansion, making it suitable for distributed and scalable automation systems.
With large onboard memory resources, high reliability, and long MTBF, the BMEH586040 is engineered for continuous industrial operation. Its redundant architecture enhances system availability and ensures stable control performance in critical process environments.
Product Specifications
| Parameter |
Description |
| Product Name |
Redundant Processor Module |
| Model |
BMEH586040 |
| Series |
Modicon M580 |
| Controller Type |
Programmable Automation Controller (PAC) |
| Redundancy Support |
Redundant processor architecture |
| Local Rack Configuration |
1 rack |
| Remote I/O Capacity |
Up to 31 racks (2 racks per remote I/O station) |
| Supported Distributed Devices |
64 devices |
| Supply Voltage |
24 V DC |
| Current Consumption |
295 mA |
| Integrated Ethernet Ports |
1 Ethernet TCP/IP service port |
|
2 Ethernet TCP/IP device network ports |
|
1 Ethernet HSBY port |
| USB Interface |
USB mini-B |
| Program and Data RAM |
64 MB |
| System Memory |
10 KB |
| Flash Memory |
4 GB expandable |
| MTBF |
600,000 hours |
| IP Rating |
IP20 |
| Application Scale |
Medium and large process applications |
| Certifications |
CE, Merchant Navy, UL, RCM, CSA, EAC |
| Standards Compliance |
EN 61131-2, EN 61000-6-4, EN 61000-6-2, EN 61010-2-201 |
| Dimensions |
134.6 × 64.6 × 130.3 mm |
| Weight |
0.849 kg |
Product Applications
• Redundant control architectures for process automation systems
• Medium and large-scale industrial process control
• Distributed automation systems with multiple remote I/O stations
• Infrastructure, energy, and continuous production processes
• Ethernet-based control systems requiring high availability
• Automation environments demanding high reliability and long uptime
Product Advantages
• Native Ethernet architecture simplifies network integration
• Redundant processor design improves system availability
• Large memory capacity supports complex control strategies
• High MTBF ensures long-term continuous operation
• Scalable remote I/O architecture supports system expansion
• Designed for demanding process automation environments
FAQ
1. What is the primary purpose of the BMEH586040 processor module?
It serves as a redundant processor for Modicon M580 systems, providing high-availability control for critical automation applications.
2. Does this processor support redundancy?
Yes, it is specifically designed to operate in redundant processor architectures.
3. How many distributed devices can the processor support?
It supports up to 64 distributed devices within the automation system.
4. What communication interfaces are integrated into the module?
It includes Ethernet TCP/IP service and device network ports, an Ethernet HSBY port, and a USB mini-B interface.
5. Is the processor suitable for large distributed systems?
Yes, it supports up to 31 remote racks across multiple I/O stations.
6. What type of memory is available on the processor?
It integrates program and data RAM, system memory, and expandable flash memory.
7. Can the processor be used in continuous process applications?
Yes, it is designed for continuous operation in medium and large process control systems.
8. How does the processor support system reliability?
Through redundancy, Ethernet synchronization, and a high MTBF rating.
9. Is the processor compliant with international industrial standards?
Yes, it complies with multiple IEC and EN standards and holds global certifications.
10. What role does this processor play in Ethernet-based automation systems?
It acts as the central control unit, managing communication, logic execution, and redundancy coordination.
Recommended Related or Same-Series Models
| Model |
Description |
| BMEH586040S |
Redundant processor module for safety-related applications |
| BMEP582040 |
Standard processor module for Modicon M580 |
| BMEP582020 |
Compact M580 processor for mid-range applications |
| BMEH584040 |
High-availability processor for process automation |
| BMEP581020 |
Entry-level M580 processor module |
| BMEH586020 |
Redundant processor module for smaller architectures |
Popular Schneider Modicon M580 Models
| Model |
Category |
Typical Application |
| BMEH586040 |
Redundant Processor |
High-availability process control |
| BMEP582040 |
Processor Module |
Standard M580 control systems |
| BMEXBP0602 |
Ethernet Backplane |
Modular M580 system infrastructure |
| BMXCPS4002 |
Power Supply Module |
Power distribution with diagnostics |
| BMXDDI1602 |
Digital Input Module |
Discrete signal acquisition |
| BMXDDO1602 |
Digital Output Module |
Actuator and output control |
