Schneider BMXNOE0100 Ethernet TCP/IP Network Module

Company Information
E-mail		sales@xmjzjsgs.com
Mobile		+8613666033393
Whatsapp		+8613666033393
WeChat		13666033393
Add		Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China

Product Overview

The BMXNOE0100 is a robust and reliable Ethernet TCP/IP communication module from Schneider Electric’s Modicon M340 series. Designed for high-performance industrial automation systems, it facilitates seamless communication between Modicon M340 PLCs and Ethernet networks. With its compact form factor and powerful data exchange capabilities, this module plays a vital role in enabling real-time control and monitoring in distributed architectures.

The module is primarily used for connecting programmable logic controllers (PLCs) to supervisory control and data acquisition (SCADA) systems, HMIs, or other Ethernet-enabled devices. It ensures fast, deterministic data transfer, remote diagnostics, and programming functions through a standard RJ45 Ethernet interface.

This module is widely adopted in factory automation, energy management, water treatment plants, infrastructure systems, and other mission-critical industrial applications that require stable network performance and operational visibility.

---

Technical Specifications

---

Applications

• Factory Automation – Real-time communication between PLCs and SCADA/HMI for manufacturing control.

• Building Management Systems – Integration of HVAC, lighting, and access systems using Ethernet.

• Water and Wastewater Treatment – Secure data exchange in distributed water processing facilities.

• Energy & Utilities – Used in substation automation, smart grid control, and energy monitoring systems.

• Material Handling – Communication backbone for conveyor control, automated storage, and retrieval systems.

• Infrastructure & Transport – Intelligent networking for traffic systems, tunnels, and railway control.

---

Advantages

• Seamless Integration: Designed specifically for the M340 platform, ensuring plug-and-play compatibility and smooth configuration via Unity Pro or EcoStruxure Control Expert.

• Real-Time Performance: Enables deterministic data communication over Ethernet, essential for high-speed automation tasks.

• Remote Diagnostics: Built-in web server provides system status, error logs, and diagnostics for preventive maintenance.

• Flexible Protocol Support: Supports multiple industrial protocols like Modbus TCP/IP, HTTP, SNMP, and FTP.

• Compact and Lightweight: Saves panel space and reduces weight, ideal for applications with spatial limitations.

• Cybersecurity Support: Supports password protection and controlled access through standard Ethernet practices.

• Firmware Upgradable: Easily update firmware remotely, avoiding the need for manual replacement or downtime.

---

Frequently Asked Questions (FAQ)

1. Q: What is the primary function of the BMXNOE0100 module?
   A: It enables Ethernet TCP/IP communication for Modicon M340 PLCs, allowing them to connect to SCADA systems, HMIs, and other Ethernet devices.

2. Q: Can this module be used for Modbus TCP communication?
   A: Yes, it fully supports the Modbus TCP protocol for data exchange across industrial networks.

3. Q: What configuration software is used with BMXNOE0100?
   A: The module is configured using Unity Pro or EcoStruxure Control Expert from Schneider Electric.

4. Q: Is it possible to access the module remotely for diagnostics?
   A: Yes, it features an embedded web server for remote diagnostics and real-time system monitoring.

5. Q: How many Ethernet ports are available on this module?
   A: There is one RJ45 port supporting 10/100 Mbps Ethernet connections.

6. Q: Is firmware upgrade supported for the BMXNOE0100?
   A: Yes, firmware can be upgraded via FTP or web interface without removing the module from service.

7. Q: Can I use this module in outdoor environments?
   A: No, it is intended for indoor industrial environments and requires an IP20-rated control cabinet.

8. Q: What kind of network services does the module support?
   A: It supports services like SNMP, HTTP, FTP, and DNS for advanced network management.

9. Q: Is the module hot-swappable?
   A: No, it is not hot-swappable and should be powered down before removal or installation.

10. Q: Does the BMXNOE0100 support redundant Ethernet communication?
    A: This model does not support Ethernet redundancy directly; such functionality would require additional networking architecture.

---
