Product Overview

The Schneider Electric EGX100MG is an Ethernet gateway designed to facilitate communication between Modbus serial devices and Ethernet networks. As part of the PowerLogic series, it enables seamless integration of devices such as meters, sensors, and other instruments into Ethernet-based systems. This gateway supports protocols including Modbus TCP/IP, HTTP, FTP, and SNMP, ensuring versatile and reliable network connectivity. The EGX100MG is engineered to provide efficient data access and management for energy monitoring and control applications.​

---

Specifications

Below is a table detailing the key specifications of the EGX100MG Ethernet Gateway:​

Specification	Details
Product Range	PowerLogic EGX100
Product or Component Type	Gateway
Number of Ports	1
Device Connections	Ethernet port protocols: FTP, HTTP, Modbus TCP/IP, SNMP (10/100 Mbit/s)
Serial Port Protocols	Modbus RTU and ASCII interfaces: RS232 and RS485 (38400/57600 baud)
Maximum Number of Connected Devices	32 directly; 247 indirectly
Power Supply	24 V DC or Power over Ethernet (PoE) IEEE 802.3af
Power Consumption	4 W
Mounting Type	DIN rail
Dimensions (H x W x D)	91 x 72 x 68 mm
Weight	0.17 kg
Operating Temperature	-25°C to +70°C
Humidity Rating	5% to 95% relative humidity (non-condensing)
Standards Compliance	UL 508, UL 60950, EN 60950, IEC 60950, CSA 22.2 No 60950, AS/NZS 60950



---

Applications

The EGX100MG Ethernet Gateway is utilized in various applications, including:​

• Energy Management Systems: Facilitates the integration of Modbus serial devices into Ethernet networks for centralized energy monitoring and management.​

• Power Distribution: Enables remote monitoring and control of power distribution equipment, enhancing operational efficiency and reliability.​

• Industrial Automation: Provides seamless communication between field devices and control systems, supporting automation processes in manufacturing and industrial settings.​

• Building Management Systems: Integrates various building systems such as lighting, HVAC, and security into a unified Ethernet network for streamlined management.​

---

Advantages

The EGX100MG offers several benefits:​

• Seamless Integration: Bridges Modbus serial devices with Ethernet networks, allowing for easy integration without extensive infrastructure changes.​

• Versatile Communication: Supports multiple protocols including Modbus TCP/IP, HTTP, FTP, and SNMP, ensuring compatibility with a wide range of devices and systems.​

• Flexible Power Options: Can be powered via 24 V DC or through Power over Ethernet (PoE), providing installation flexibility.​

• Compact and Robust Design: DIN rail mounting and compact dimensions make it suitable for various installation environments, while its robust build ensures durability.​

• Wide Operating Range: Operates effectively in temperatures ranging from -25°C to +70°C and in humidity levels from 5% to 95%, accommodating diverse environmental conditions.​

---
