Product Introduction
The Schneider STBDDI3610K Standard Digital Input Kit is part of the Modicon STB modular distributed I/O product family. It is designed to provide reliable digital input signal acquisition for industrial automation systems that require flexibility, scalability, and ease of maintenance.
This standard digital input kit features six digital inputs supporting both positive and negative logic. It operates with a rated supply voltage of 24 V DC and is optimized for distributed architectures through compatibility with most major industrial fieldbus networks. The module is suitable for integration into modular machine control systems where stable signal detection and system expandability are essential.
With an IP20 protection rating and compliance with international industrial standards, the STBDDI3610K is widely used in machine automation environments such as packaging, bottling, assembly, and semiconductor manufacturing. It forms an integral part of flexible machine control solutions within the MachineStruxure architecture.
Product Specifications
| Parameter |
Description |
| Product Name |
Standard Digital Input Kit |
| Model |
STBDDI3610K |
| Series |
Modicon STB |
| Module Type |
Digital Input |
| Number of Inputs |
6 digital inputs |
| Input Logic |
Positive and negative logic |
| Rated Supply Voltage |
24 V DC |
| Logic Bus Consumption |
55 mA at 5 V DC |
| Fieldbus Compatibility |
Compatible with most major fieldbus networks |
| IP Rating |
IP20 |
| Standards Compliance |
EN/IEC 61131-2 Type 3 |
| Certifications |
FM Class 1 Division 2, CE, UL, CSA |
| Compatible Base |
STBXBA1000 |
| Compatible Power Modules |
STBPDT3100, STBPDT3105 |
| Included Components |
STBDDI3610 module, STBXTS2100 spring connector, STBXTS1100 screw connector, STBXBA1000 base |
| Dimensions |
125 × 18.4 × 65.1 mm |
| Weight |
0.112 kg |
Product Applications
• Digital input signal acquisition for packaging, bottling, and assembly machinery
• Monitoring of sensors and switches in distributed I/O systems
• Modular machine automation in textile and printing industries
• Input signal processing in semiconductor manufacturing equipment
• Integration with Modicon STB architectures for flexible machine control
• Industrial automation systems requiring compact and modular input expansion
Product Advantages
• Supports both positive and negative logic inputs for flexible signal handling
• Modular STB design allows easy expansion and simplified maintenance
• Compatible with a wide range of industrial fieldbus networks
• Industrial certifications ensure reliable operation in demanding environments
• Compact structure supports high-density distributed I/O configurations
• Seamless integration into MachineStruxure-based machine control systems
FAQ
1. What is the main function of the STBDDI3610K kit?
It provides six digital input channels for monitoring field signals in industrial automation systems.
2. What type of input logic does this module support?
The module supports both positive and negative logic input signals.
3. What supply voltage is required for operation?
The rated operating voltage of the module is 24 V DC.
4. Is this module suitable for distributed I/O architectures?
Yes, it is specifically designed for modular distributed I/O systems within the Modicon STB range.
5. Can the module be integrated with other STB components?
Yes, it works with the STBXBA1000 base and STBPDT3100/3105 power distribution modules.
6. Does the module support fieldbus communication?
Yes, it is compatible with most major industrial fieldbus networks.
7. What standards does the module comply with?
It complies with EN/IEC 61131-2 Type 3 and is certified by FM, CE, UL, and CSA.
8. Is the module suitable for industrial machine environments?
Yes, it is designed for use in packaging, textile, printing, and semiconductor machinery.
9. How does this module support flexible machine control?
Its modular design allows easy configuration and expansion within MachineStruxure architectures.
10. Can this module be used in systems requiring high reliability?
Yes, its certified design and industrial-grade construction make it suitable for reliable automation systems.
Recommended Related or Same-Series Models
| Model |
Description |
| STBDDI3610 |
Standard digital input module, 6 inputs |
| STBDDI3620K |
Digital input kit with extended diagnostics |
| STBDDI3630K |
Industrial digital input kit for modular STB systems |
| STBDDO3600K |
Standard digital output kit, solid-state outputs |
| STBDDI3725KS |
Basic digital input kit, 16 inputs |
| STBDAI3725KS |
Analog input kit for Modicon STB systems |
Popular Schneider Modicon STB Models
| Model |
Category |
Typical Application |
| STBDDI3610K |
Digital Input Kit |
Standard discrete signal acquisition |
| STBDDO3600K |
Digital Output Kit |
Actuator and relay control |
| STBDDI3725KS |
Digital Input Kit |
High-density input monitoring |
| STBDAI3725KS |
Analog Input Kit |
Analog signal measurement |
| STBDAO3725KS |
Analog Output Kit |
Analog control output |
| STBXBA1000 |
I/O Base |
Modular STB mounting and expansion |
