Schneider TM3DM24RG Discrete IO modules

Product Overview

The Schneider TM3DM24RG is a discrete input/output (I/O) module designed for modular automation systems, offering reliable digital signal control in industrial environments. Part of Schneider Electric’s TM3 series, this module combines discrete digital inputs and relay outputs, making it ideal for applications that require both sensing and switching capabilities.

This module supports 24 V DC digital inputs and relay outputs, delivering electrical isolation and enhanced switching power. Its robust construction and compact design enable easy integration into TM3 modular I/O systems, suitable for machine control, factory automation, and process applications.

Technical Specifications

Industry Applications

• Machine and Factory Automation

• Process Control Systems

• Building Automation

• Packaging and Material Handling

• HVAC Control

• Water and Wastewater Treatment

• Food and Beverage Manufacturing

• Automotive Industry

Key Advantages

• Combined Input and Relay Output: Supports both discrete sensing and high-current switching in a single module.

• High Load Capacity: Relay outputs rated up to 5 A per contact, suitable for controlling heavy loads.

• Electrical Isolation: Relay outputs provide galvanic isolation between control signals and loads.

• Robust and Reliable: Designed to operate reliably across wide temperature and humidity ranges.

• Compact and Modular: Fits within TM3 modular I/O systems, allowing easy expansion and maintenance.

• Fast Response: Typical response times below 10 ms for effective control.

• DIN Rail Mounting: Simplifies installation and wiring in control cabinets.

• Certified and Compliant: Meets international safety and environmental standards.

Frequently Asked Questions (FAQ)

1. How many inputs and outputs does the TM3DM24RG module have?
   It has 12 digital inputs and 8 relay outputs.

2. What voltage levels do the inputs and outputs operate at?
   Inputs operate at 24 V DC nominal; relay outputs switch up to 250 V AC or 30 V DC.

3. What is the maximum current rating for each relay output?
   Each relay contact is rated for 5 A.

4. What is the typical response time of the module?
   Response time is typically under 10 milliseconds.

5. What mounting options are available?
   The module mounts on a standard DIN rail.

6. Is the module suitable for harsh environments?
   It is rated for operation between -25°C and +60°C with 5% to 95% humidity.

7. Does the module provide electrical isolation?
   Yes, relay outputs provide galvanic isolation.

8. Can the module be used with other Schneider TM3 modules?
   Yes, it is fully compatible with the TM3 modular I/O system.

9. What certifications does the TM3DM24RG hold?
   It is CE, UL, cUL certified and RoHS compliant.

10. Is the module suitable for controlling inductive loads?
    Yes, relay outputs are suitable for resistive and inductive loads within specified ratings.
