Schneider TM3TI8TG Analog Input Module

Product Introduction

The Schneider TM3TI8TG Analog Input Module is part of the TM3 I/O series and provides a highly reliable and efficient solution for measuring and converting analog signals in industrial applications. The module is designed to accept analog signals from various types of sensors, such as temperature, pressure, and flow, and convert them into digital data that can be processed by control systems like PLCs. The TM3TI8TG module features 8 input channels and offers an excellent range of input types, including thermocouples and RTDs, making it suitable for a wide variety of industrial measurement and control applications.

The TM3TI8TG module supports communication through Modbus RTU and Modbus TCP protocols, ensuring seamless integration into existing automation systems. It is particularly useful in industries where high-accuracy measurements are needed, such as process control, HVAC, and energy management systems. This module can be easily mounted on a DIN rail, saving space in control panels and making installation quick and easy.

Product Specifications

Product Applications

The Schneider TM3TI8TG Analog Input Module is designed to be versatile and adaptable for a variety of industrial applications that require the acquisition of temperature and resistance measurements. Here are some of the primary applications:

• Process Control Systems: The module is widely used in process control applications to measure the temperature, pressure, and other physical properties of processes. It supports both thermocouple and RTD sensors for accurate measurement of these variables.

• HVAC Systems: In HVAC systems, it is used to measure the temperature of air, water, and other fluids, ensuring that the system operates within optimal parameters for energy efficiency.

• Energy Management: The module is employed in energy management systems to monitor the performance of heating and cooling equipment, as well as to ensure that energy consumption is within acceptable limits.

• Building Automation: In building automation, the TM3TI8TG is used to interface with sensors that monitor environmental factors like room temperature, humidity, and pressure, allowing for automatic adjustments to heating, ventilation, and air conditioning.

• Machine Monitoring: The module is also used in machinery monitoring systems, where it helps measure temperature and other critical variables to ensure the machinery operates within safe and efficient ranges.

• Water Treatment: The TM3TI8TG is useful in water treatment plants for measuring parameters like temperature and flow rate, which are vital for maintaining optimal water quality and treatment processes.

Product Advantages

1. High-Resolution Measurement: With a 16-bit ADC, the TM3TI8TG provides high-resolution data acquisition, ensuring that even subtle variations in temperature or resistance are accurately captured.

2. Wide Range of Supported Sensors: The module supports both thermocouples and RTDs, offering a wide range of sensor options for different measurement needs and providing flexibility for various applications.

3. Precise Temperature Measurement: The module is capable of measuring a wide range of temperatures, from -200°C to 850°C for thermocouples, making it suitable for applications that require extreme temperature monitoring.

4. Seamless Integration: The TM3TI8TG supports Modbus RTU and Modbus TCP communication protocols, allowing for easy integration into most industrial automation networks, including PLCs, DCS, and SCADA systems.

5. Compact and Space-Efficient: The module is designed for DIN rail mounting, which helps save space in control panels and makes installation easier in cramped environments.

6. Robust Performance: Built to meet industrial standards, the TM3TI8TG is durable and reliable even in harsh operating conditions, ensuring long-term performance and minimal downtime.

FAQs

1. What types of analog input signals are supported by this module?
   This module supports analog signals from thermocouples, RTDs, and other common industrial sensors used for temperature and resistance measurements.

2. How many channels are available for input?
   The module provides 8 analog input channels, allowing for simultaneous monitoring of multiple signals from various sensors.

3. What is the resolution of the analog-to-digital conversion?
   The module features a high-resolution 16-bit ADC, which ensures precise and accurate conversion of analog signals into digital data for processing.

4. Can this module support both thermocouples and RTDs?
   Yes, it is designed to support both thermocouple and RTD sensors, making it versatile for different types of industrial measurements.

5. What communication protocols are supported for data transfer?
   The module supports Modbus RTU and Modbus TCP communication protocols, ensuring seamless integration into most industrial control networks and automation systems.

6. What is the typical power consumption of the module?
   The module consumes a low power of just 2.5W, making it energy-efficient for industrial applications.

7. How is the module mounted in control panels?
   The module is designed for easy installation on a DIN rail, which is a common mounting solution for control panels in industrial automation systems.

8. What is the temperature range supported by the module for thermocouple inputs?
   The module supports a wide temperature range for thermocouple inputs, typically from -200°C to 850°C, depending on the type of thermocouple used.

9. Is it compatible with other Schneider Electric products in an automation system?
   Yes, the module is designed to integrate seamlessly with other Schneider Electric products, including PLCs, controllers, and I/O systems, in a unified automation system.

10. What is the input resistance for RTD sensors?
    The module supports RTD sensors with a typical input resistance of 100Ω, which is commonly used for temperature measurement with RTDs.
