Product Overview
The Schneider TSXDMZ28DTK Discrete Solid State I/O Base is a high-performance I/O module designed for reliable operation in industrial automation systems. It serves as an interface between the control system and field devices such as sensors, actuators, and other electrical components. The module features solid-state inputs and outputs, which offer faster response times and increased durability compared to traditional mechanical relays. The TSXDMZ28DTK is specifically designed for use in Modicon Quantum PLC systems and is ideal for applications that require high-speed, high-reliability operations in harsh industrial environments.
Product Specifications
| Specification | Details |
|---|---|
| Product Type | Discrete Solid State I/O Base |
| Model | TSXDMZ28DTK |
| Input/Output Type | 28 Discrete Solid State I/O |
| Rated Input Voltage | 24V DC |
| Rated Output Voltage | 24V DC |
| Operating Temperature | -20°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Dimensions (L x W x H) | 180 x 260 x 55 mm |
| Weight | 0.33 kg |
| Mounting Type | DIN Rail or Panel Mounting |
| Mounting Orientation | Horizontal or Vertical |
| Communication Interface | Modbus, CANopen, or similar protocols |
| Environmental Protection | IP20 |
| Certification | CE, UL, CSA, RoHS |
Product Applications
The TSXDMZ28DTK Discrete Solid State I/O Base is ideal for a wide range of applications in industrial automation systems, including but not limited to:
-
Manufacturing Automation: Used for controlling sensors, actuators, and relays in automated production lines.
-
Process Control: Ideal for industries such as oil & gas, chemical, and pharmaceutical where high-speed control and reliability are critical.
-
Machine Control: Integrated into machine control systems for faster response times and higher durability in harsh environments.
-
Building Automation: Used in building control systems for HVAC, lighting, and other critical infrastructure.
Product Advantages
-
High-Speed Performance: The solid-state I/O ensures faster response times compared to mechanical relays, providing quicker reactions in high-speed applications.
-
Durability: With solid-state components, the module is highly resistant to wear and tear, making it more reliable and longer-lasting than traditional mechanical I/O systems.
-
Compact Design: The module’s compact size makes it easy to integrate into existing systems and saves space in control panels.
-
Versatile Mounting Options: The ability to mount both horizontally and vertically gives flexibility in installation and makes it suitable for various setups.
-
Wide Temperature Range: Capable of operating in extreme temperatures, this module is built for harsh industrial environments.
-
Reduced Power Consumption: Solid-state I/O systems consume less power than traditional relays, leading to more efficient energy use.
-
Cost-Effective: While offering high performance, the TSXDMZ28DTK provides a more economical solution compared to mechanical alternatives in many use cases.
Frequently Asked Questions (FAQ)
-
What is the purpose of the Schneider TSXDMZ28DTK?
-
The TSXDMZ28DTK is used to interface discrete field devices, like sensors and actuators, with control systems, providing high-speed, reliable input/output capabilities in industrial automation systems.
-
-
Is this module compatible with all Modicon PLCs?
-
Yes, it is specifically designed for use with Modicon Quantum PLCs, but it can be compatible with other Schneider PLC systems as well, depending on the communication protocol.
-
-
What are the input/output voltage ratings?
-
The module operates with both 24V DC input and output.
-
-
Can this module be used in outdoor environments?
-
The TSXDMZ28DTK has an IP20 rating, meaning it should be used in environments that are protected from direct contact with harmful dust and moisture. For outdoor use, additional protective housing may be required.
-
-
What are the temperature ranges for operation and storage?
-
The module operates in temperatures between -20°C and +60°C and can be stored in temperatures from -40°C to +85°C.
-
-
What protocols are supported by this module?
-
It supports standard industrial communication protocols like Modbus, CANopen, and similar protocols.
-
-
How is the module mounted?
-
The TSXDMZ28DTK can be mounted using a DIN rail or directly onto a panel, offering flexible installation options.
-
-
What is the weight of the module?
-
The module weighs 0.33 kg.
-
-
Can I use the module for controlling actuators and sensors simultaneously?
-
Yes, it supports both types of devices and can be configured for either input or output, or a mix of both.
-
-
What certifications does the product have?
-
The TSXDMZ28DTK is CE, UL, CSA, and RoHS certified, ensuring compliance with international safety and environmental standards.
-
