Product Introduction

The Triconex 3601 Digital Output Module is part of the renowned Tricon system, designed for high-reliability, fault-tolerant, and safety-critical industrial applications. This module is part of the Triconex safety instrumented system (SIS) family, which is widely recognized for its ability to prevent accidents and ensure safe operations in critical environments. The 3601 module is used for output control of industrial processes by converting digital control signals into physical outputs that can drive actuators, valves, and other devices essential for system operations.

The Triconex 3601 is an essential component in various industries, including oil and gas, chemical processing, power generation, and industrial automation, where operational safety and reliability are of utmost importance. This module is part of a robust and scalable control system that offers flexibility, high availability, and safety compliance, such as IEC 61508 and IEC 61511 standards.

---

Product Specifications

Below are the detailed specifications of the Triconex 3601 Digital Output Module:

---

Product Applications

The Triconex 3601 Digital Output Module is commonly used in various safety-critical applications where precise control of digital outputs is essential. These applications span across multiple industries, where the module ensures reliable output control for safety, shutdown, and process control systems:

• Safety Instrumented Systems (SIS): The 3601 module is integral to SIS applications where it directly drives safety-related actuators such as valves and emergency shutdown systems (ESD).

• Emergency Shutdown Systems (ESD): Used to trigger emergency shutdowns in processes to ensure safety when hazardous conditions arise, such as in refineries, chemical plants, and oil & gas operations.

• Process Control Systems: The module is employed in process automation, controlling processes through digital outputs that activate alarms, indicators, and other process controls.

• Machine Safety: It drives outputs for machine safety control systems, ensuring that critical machines and systems operate within safe parameters and conditions.

• Control of Actuators and Valves: Used in applications requiring control of valves, actuators, or other field devices that require digital on/off signals.

• Industrial Automation Systems: Integrated into large-scale industrial control systems where high reliability and fault tolerance are needed to ensure continuous operation.

---

Product Advantages

The Triconex 3601 Digital Output Module offers numerous advantages for industrial operations that require high reliability and safety. These benefits make it a top choice for users looking to ensure robust control systems in critical environments.

• High Reliability: The 3601 module provides fault-tolerant performance, ensuring reliable output even in the event of partial system failures. This is especially crucial for safety-critical systems in industries like chemical and oil & gas.

• Fast Response Time: With a nominal response time of ≤ 10 ms, the module offers rapid output control, ensuring that the system responds swiftly to changes and maintains operational efficiency.

• High Safety Integrity: Designed to meet stringent safety standards, the Triconex 3601 supports functional safety requirements such as IEC 61508, IEC 61511, and other international safety certifications.

• Flexible Output Configuration: The 16 individually configurable output channels give users the flexibility to design the system for their specific application needs.

• Wide Operating Temperature Range: With an operating temperature range of -40°C to +70°C, the module is suitable for use in a variety of challenging environments, from extreme cold to high temperatures.

• Robust Mechanical Design: The module features excellent shock and vibration resistance, making it durable in environments prone to mechanical stress.

• Compact Size: The module’s compact design (140 x 140 x 32 mm) makes it easy to integrate into tight spaces and existing control panels.

• Certifications and Compliance: The module is certified by several recognized standards, including UL, CE, CSA, FM, and ATEX, ensuring it meets global safety and operational standards.

• Ease of Installation: The module features screw terminal connections and a DIN rail mounting system, simplifying installation and maintenance procedures.

• Energy Efficient: With a low power consumption of 1.5 W, the module contributes to overall system energy efficiency.

---

FAQ

1. What is the primary function of the Triconex 3601 module?

   • The Triconex 3601 is a digital output module used for controlling actuators, valves, and other devices in safety-critical systems, ensuring reliable and fault-tolerant performance.

2. How many output channels does the 3601 module have?

   • The 3601 module features 16 individually configurable output channels.

3. What is the voltage rating for the output of the 3601 module?

   • The output voltage for the module is 24V DC (nominal).

4. What is the maximum current per output channel?

   • Each output channel can handle a maximum current of 0.5 A.

5. What is the power consumption of the Triconex 3601 module?

   • The module consumes 1.5 W of power during operation.

6. What is the operating temperature range for the module?

   • The operating temperature range is from -40°C to +70°C, allowing the module to be used in a variety of harsh environments.

7. What certifications does the 3601 module have?

   • The module is certified with UL, CE, CSA, FM, and ATEX, ensuring compliance with global safety and operational standards.

8. Can the 3601 module withstand mechanical shock or vibration?

   • Yes, the module is resistant to shock (15g) and vibration (2g), making it suitable for industrial environments with mechanical stresses.

9. How is the module mounted?

   • The Triconex 3601 module is DIN rail mountable, simplifying installation in control panels.

10. What type of signal does the 3601 module use for output?

• The module uses digital signals (on/off) to control actuators and devices.

---
