Product Introduction
The Triconex 3614E Module Supervised DO Assy is an advanced digital output module designed for use within Triconex’s safety systems. It is engineered to provide reliable and fail-safe digital output control in critical industrial processes where safety is paramount. The module serves as an essential part of the Triconex safety system, enabling the supervision and control of output devices in a variety of safety-related applications.
The Triconex 3614E module supports highly reliable, supervised, and redundant output channels, ensuring that all connected devices operate in a controlled, fail-safe manner. This module is ideal for use in industries such as oil and gas, power generation, chemical processing, and more, where operational safety and reliability are non-negotiable. By integrating this module into your safety system, you gain the assurance that your outputs are continuously monitored and remain in a safe state during normal and fault conditions.
Product Specifications
| Parameter | Value |
|---|---|
| Manufacturer | Triconex |
| Model Number | 3614E |
| Type | Supervised Digital Output Module |
| Operating Voltage | 24 VDC |
| Output Type | Digital Output (Relay) |
| Output Channels | 4 Digital Output Channels |
| Contact Rating | 2 A, 250 VAC |
| Dimensions | 114.3 ×127 × 107.95 mm |
| Weight | 1.5 kg |
| Protection Rating | IP20 |
| Operating Temperature | -20°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Response Time | ≤ 20 ms |
| Power Consumption | 5 W (Typical) |
| Mounting Type | DIN Rail Mounting |
| Certification | SIL 3 (Safety Integrity Level) |
Product Applications
The Triconex 3614E Module Supervised DO Assy is suitable for safety-critical applications in various industries. Its key uses include:
-
Safety Instrumented Systems (SIS): The 3614E module is commonly used in SIS to ensure the safe operation of systems that monitor and control industrial processes.
-
Emergency Shutdown Systems (ESD): It plays an essential role in ESD applications, where immediate actions such as shutting down a system are required in the event of a hazardous situation.
-
Process Control Systems: The module ensures the safe and reliable operation of digital output devices in process control environments, offering seamless integration with other safety systems.
-
Fire and Gas Detection Systems: It is widely used in fire and gas detection systems to actuate alarms, shutdown valves, and other emergency measures in hazardous conditions.
-
Machine Safety: The module provides the necessary control for critical machine safety, activating emergency stop functions and ensuring safe operational states during abnormal conditions.
-
Oil & Gas: In the oil and gas industry, it is used to monitor and control critical operations, ensuring that any faults are detected and output devices are safely deactivated.
-
Power Generation: The module ensures safety in power generation systems, where output control is critical for maintaining system integrity and preventing damage to expensive equipment.
Product Advantages
-
Safety Integrity Level (SIL 3): The 3614E module is certified to SIL 3, providing the highest level of safety for mission-critical applications.
-
Supervised Outputs: The module continuously supervises output channels to ensure their safe and reliable operation, providing real-time feedback to the system.
-
Compact and Space-Saving: With dimensions of 114.3 ×127 × 107.95 mm, the module offers a compact design that allows it to fit in limited spaces, perfect for integration into control panels and systems with tight layouts.
-
High Reliability: The 3614E is built for high reliability, operating in harsh conditions, with a response time of ≤ 20 ms, ensuring quick and effective action in critical scenarios.
-
Wide Operating Temperature Range: This module operates effectively in a wide temperature range of -20°C to +60°C, making it suitable for use in various environments.
-
Low Power Consumption: The 3614E has a typical power consumption of only 5 W, contributing to energy savings and long-term cost-effectiveness.
-
Easy Installation: With DIN rail mounting, the module can be quickly and easily installed in a range of industrial environments, offering user-friendly installation procedures.
-
Flexible Integration: The module integrates seamlessly with Triconex safety systems and is fully compatible with other Triconex I/O modules, making it a versatile addition to your safety control system.
-
Durable and Robust: With an IP20 protection rating, it is well-suited for environments where dust and other particulate matter are present, though it is not recommended for exposure to water.
-
Cost-Effective Solution: The Triconex 3614E offers a high-performance, cost-effective solution for monitoring and controlling digital outputs in safety-critical environments.
Frequently Asked Questions (FAQ)
-
What is the primary function of the Triconex 3614E module?
The primary function of the Triconex 3614E is to supervise and control digital output devices in safety-related applications, ensuring reliable and fail-safe operation. -
What is the output type of the 3614E module?
The module provides digital output via relay contacts, with four output channels in total. -
What is the power supply requirement for the module?
The 3614E operates on a 24 VDC power supply. -
How many output channels does the 3614E have?
The module offers four digital output channels for controlling output devices. -
What certifications does the 3614E module have?
It is certified to SIL 3, which meets high safety integrity standards for critical applications. -
What are the dimensions of the Triconex 3614E module?
The dimensions of the module are 114.3 ×127 × 107.95 mm. -
What is the weight of the module?
The 3614E weighs 1.5 kg. -
What is the operating temperature range of the module?
The module operates within a temperature range of -20°C to +60°C. -
How is the module mounted?
The Triconex 3614E module is designed for DIN rail mounting, allowing for easy installation. -
What industries benefit from using the 3614E module?
Industries such as oil and gas, chemical processing, power generation, and industrial automation benefit from the safety features of the 3614E.
