Product Introduction
The Triconex 4107 Communication Module is a vital component within the Triconex safety and control platform, designed for high-integrity and high-availability industrial automation environments. Manufactured by Triconex, a brand under Schneider Electric, this module facilitates robust, secure, and deterministic communication between the Tricon main processor chassis and external control or monitoring systems.
The 4107 module enables peer-to-peer data exchange, system-wide redundancy management, and integration with third-party Distributed Control Systems (DCS), SCADA, and Human-Machine Interfaces (HMI). Whether it’s part of a safety instrumented system (SIS) or a critical control application, the Triconex 4107 is engineered for environments where zero communication failure is not just a goal—it is a requirement.
Built with fault-tolerant architecture, this module supports TMR (Triple Modular Redundant) operation and complies with the highest safety integrity levels, including SIL 3 per IEC 61508. Its high-speed communication capabilities, support for various industrial protocols, and seamless hot-swapping make it indispensable for process-critical applications in oil & gas, nuclear, petrochemical, power generation, and transportation sectors.
Technical Specifications
| Parameter | Details |
|---|---|
| Model Number | 4107 |
| Manufacturer | Triconex (Schneider Electric) |
| Module Type | Communication Interface Module |
| System Compatibility | Tricon v10 system chassis |
| Supported Architectures | TMR (Triple Modular Redundant) |
| Communication Protocols | Ethernet, Modbus TCP/IP, Modbus RTU, OPC |
| Functionality | Peer-to-peer, remote access, external I/O exchange |
| Redundancy Support | Yes, built-in redundancy |
| Hot-Swappable | Yes |
| Diagnostic Capability | Online diagnostics, status LEDs |
| Firmware Upgradeable | Yes (via system tools) |
| Operating Voltage | Supplied from chassis (typically 5V or 24V) |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Humidity Range | 5% to 95% RH, non-condensing |
| Shock/Vibration Resistance | Industrial grade, compliant with ANSI/ISA standards |
| Dimensions (W x H x D) | 200 × 100 × 50 mm |
| Weight | 1.8 kg |
| Mounting | Direct plug-in to system backplane |
| Certifications | SIL 3 (IEC 61508), CE, ATEX, GOST-R |
Product Applications
The Triconex 4107 Communication Module is deployed across industries that rely on continuous process safety and real-time system monitoring, including:
-
Oil & Gas (Upstream, Midstream, Downstream):
Seamless communication between safety controllers and DCS, enabling emergency shutdown systems (ESD), fire & gas detection, and blowout preventer (BOP) monitoring. -
Power Generation (Nuclear, Thermal, Hydro):
Reliable interfacing between turbine control systems, steam loop safety instrumentation, and plant-wide monitoring networks. -
Chemical and Petrochemical Industries:
Supervises toxic gas levels, pressure vessel conditions, and interlocks between distributed safety nodes via industrial protocols. -
Water & Wastewater Treatment:
Ensures safe communication between distributed pump stations, chlorine dosing systems, and filtration units. -
Transportation (Rail, Metro, Airports):
Coordinates environmental monitoring and emergency response systems across complex infrastructure. -
Pharmaceutical Manufacturing:
Enables high-integrity process control integration with MES/SCADA, supporting batch records and alarm handling.
Product Advantages
-
True TMR Support:
Fully compatible with Tricon TMR architecture, providing unparalleled fault tolerance. -
Hot-Swap Capability:
Supports online replacement without interrupting system operations, minimizing downtime. -
Protocol Versatility:
Native support for Ethernet, Modbus TCP/RTU, and OPC ensures wide integration flexibility. -
Redundant Communication Paths:
Supports primary/backup channels for network reliability in mission-critical operations. -
Advanced Diagnostics:
Real-time health monitoring, status indication LEDs, and onboard self-checks for proactive maintenance. -
Secure and Deterministic Data Exchange:
Guaranteed cycle times for deterministic communication across safety boundaries. -
Firmware Upgradeable:
Allows remote firmware updates for lifecycle management and security patching. -
Robust Build for Harsh Environments:
Industrial-grade tolerance to temperature, vibration, and electrical noise. -
Standard Compliance:
SIL 3 certified per IEC 61508 and compliant with industry safety and quality standards. -
Long-Term Product Support:
Supported by Schneider Electric’s global service network and lifecycle management plans.
Frequently Asked Questions (FAQ)
-
Q: What is the primary function of the Triconex 4107 module?
A: It serves as a communication interface between the Tricon system and external devices such as DCS, SCADA, or peer Tricon units. -
Q: Is the 4107 module hot-swappable?
A: Yes, it can be replaced while the system is live without requiring a shutdown. -
Q: Which communication protocols are supported?
A: It supports Ethernet, Modbus TCP, Modbus RTU, and OPC for system interoperability. -
Q: Can it be used in SIL-rated applications?
A: Absolutely. The 4107 module is certified for SIL 3 environments in accordance with IEC 61508. -
Q: How is it installed?
A: It mounts directly into the Tricon system chassis backplane with plug-and-play configuration. -
Q: What happens if the communication module fails?
A: The system’s TMR architecture and redundancy features allow continued operation with automatic failover. -
Q: Does the 4107 require external power?
A: No, it draws its power directly from the system chassis, typically 5V or 24V DC. -
Q: Can firmware be updated remotely?
A: Yes, using Schneider Electric’s system configuration tools, the firmware can be safely updated. -
Q: Is it compatible with Tricon CX platforms?
A: The 4107 is designed for traditional Tricon v10 systems; compatibility with CX systems should be verified per application. -
Q: What diagnostics are provided?
A: The module offers onboard LEDs, error flags, and system event logs for troubleshooting.
Related Models from the Same Series or Category
| Model | Function | Compatibility | Key Feature |
|---|---|---|---|
| Triconex 4119A | Communication Module (Modbus) | Tricon V10 | Modbus RTU over serial port |
| Triconex 4118 | Peer Link Interface | Tricon V10 | TMR peer communication |
| Triconex 4201 | Communication Interface | Tricon V10 | Used for data exchange via Ethernet |
| Triconex 4351B | Main Processor Module | Tricon V10 | Core logic processing (TMR CPU) |
| Triconex 4000098 | Network Switch Module | Tricon Platforms | Managed industrial networking |
| Triconex 3706 | Chassis Backplane | Tricon System | Supports up to 8 modules |
Popular Triconex Models (Same Brand)
| Model | Type | Primary Function | Application Area |
|---|---|---|---|
| Triconex 3008 | Main Processor | TMR-based logic processing | Safety & critical control systems |
| Triconex 3625 | Digital Input Module | Captures discrete field signals | ESD, F&G, interlocks |
| Triconex 3700A | Power Supply Module | Redundant power for system chassis | Universal use |
| Triconex 3511 | Analog Input Module | Reads process analog signals | Pressure, temperature, level, etc. |
| Triconex 3664 | Analog Output Module | Sends analog control signals | Valve or actuator control |
| Triconex 4200 | Network Communication Gateway | Integrates system to plant-wide network | OPC, Ethernet/IP, Modbus TCP |
