Product Overview
The Triconex 9561-810 Industrial Controller is a safety-certified controller designed to deliver reliable, fault-tolerant control in demanding industrial environments. Built with a triple modular redundant (TMR) architecture, this controller ensures continuous operation and high system availability for safety instrumented systems (SIS). It is suitable for complex process control and safety applications, meeting rigorous industry standards.
Key Features
-
SIL 3 certified for high-integrity safety systems
-
Triple Modular Redundancy (TMR) architecture for fault tolerance
-
High-speed real-time processing capabilities
-
Scalable and flexible for various application requirements
-
Compatible with Triconex 3000 and 7000 series platforms
-
Supports extensive communication and I/O options
-
Robust design for harsh industrial conditions
Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | 9561-810 |
| Controller Type | Industrial Safety Controller |
| Architecture | Triple Modular Redundancy (TMR) |
| Processing Speed | High-speed real-time processing |
| Memory | Configurable, several MBs |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Humidity Range | 5% to 95% non-condensing |
| Dimensions | 200 x 60 x 40 mm |
| Weight | 0.5 kg |
| Safety Certifications | SIL 3 (IEC 61508), IEC 61511 compliant |
Industry Applications
-
Safety and process control in oil and gas
-
Chemical and petrochemical plants
-
Power generation facilities
-
Nuclear power safety systems
-
Pharmaceutical manufacturing
-
Water and wastewater treatment
Frequently Asked Questions (FAQ)
Q1: What safety integrity level is supported by the 9561-810 controller?
It is certified for SIL 3 safety applications.
Q2: What architecture does the controller use?
Triple Modular Redundancy (TMR) for fault tolerance.
Q3: Which industries is this controller suited for?
Oil & gas, chemical, power generation, nuclear, pharmaceutical, and water treatment.
Q4: What are the operating temperature limits?
0°C to 60°C.
Q5: What are the dimensions and weight?
200mm x 60mm x 40 mm; approx. 0.5 kg.
Q6: Is it compatible with other Triconex systems?
Yes, compatible with 3000 and 7000 series.
Q7: How does the TMR architecture enhance reliability?
It provides triple redundancy to detect and tolerate faults without interrupting operation.
Q8: What communication options are available?
Supports various industrial protocols and communication modules depending on configuration.
Q9: Is it designed for harsh environments?
Yes, robust design for demanding industrial conditions.
Q10: What are typical applications?
Used in safety-critical and complex control applications requiring high availability.
