Product Introduction:
The Triconex 9662-6 DO Terminal Panel is an essential interface module designed to facilitate the secure and reliable connection of discrete digital output signals from Triconex safety systems to field devices. Specifically engineered for use in critical safety applications, this terminal panel ensures that output signals are accurately transmitted to control devices such as valves, actuators, and alarms.
With a compact and robust design, the 9662-6 DO Terminal Panel integrates seamlessly into safety instrumented systems (SIS), providing clear terminal points that simplify wiring and maintenance. The module is manufactured by Triconex, a trusted brand under Emerson, renowned worldwide for its high safety and reliability standards in process automation and industrial safety control.
Product Specifications:
| Parameter | Details |
|---|---|
| Model Number | 9662-6 |
| Manufacturer | Triconex (Emerson) |
| Product Type | Digital Output Terminal Panel |
| Number of Channels | 6 discrete digital output channels |
| Terminal Type | Screw clamp terminals with secure locking |
| Output Signal Type | Discrete digital output signals |
| Output Voltage | Up to 30 V DC |
| Output Current | Maximum 0.5 A per channel |
| Insulation Resistance | > 1 GΩ |
| Dielectric Strength | 2.5 kV AC for 1 minute |
| Operating Temperature Range | -20°C to +70°C |
| Storage Temperature Range | -40°C to +85°C |
| Humidity Range | 5% to 95% non-condensing |
| Mounting Type | DIN rail or panel mounting |
| Dimensions (L × W × H) | 114.3 ×127 × 107.95 mm |
| Weight | 0.38 kg |
| Housing Material | Flame-retardant plastic with corrosion-resistant metal terminals |
| Certifications | SIL 3 certified, CE compliant, UL recognized |
Product Applications:
-
Safety Instrumented Systems (SIS): Facilitates connection of digital output signals to safety actuators, valves, and alarms in emergency shutdown and safety control systems.
-
Process Automation: Controls digital outputs for various process control devices in chemical, petrochemical, and power plants.
-
Industrial Machinery: Provides safe and reliable digital output connections for automated machinery requiring safety-rated outputs.
-
Fire and Gas Detection Systems: Interfaces digital output commands to fire suppression and gas alarm systems.
-
Power Generation: Used in turbine trip control and safety shutdown mechanisms.
-
Emergency Shutdown Systems (ESD): Acts as a secure interface for output signals in emergency control scenarios.
Product Advantages:
-
High Reliability: Designed to withstand harsh industrial conditions including vibration and temperature extremes.
-
Safety Compliance: Certified to SIL 3 standards, ensuring suitability for the highest safety integrity requirements.
-
User-Friendly Installation: Screw clamp terminals with locking features enable quick, secure wiring and easy maintenance.
-
Compact and Space-Saving: Smaller footprint compared to larger terminal panels, ideal for tight cabinet spaces.
-
Durable Construction: Flame-retardant and corrosion-resistant materials enhance longevity and safety.
-
Flexible Mounting: Compatible with both DIN rail and panel mounting methods, providing installation versatility.
-
Clear Terminal Markings: Helps technicians quickly identify connection points, minimizing wiring errors.
-
Enhanced Diagnostics: Centralizes output connections, simplifying troubleshooting and fault detection.
-
Brand Trust: Part of the Emerson Triconex portfolio, known for rigorous quality control and performance.
Frequently Asked Questions (FAQ):
-
What is the main function of the Triconex 9662-6 DO Terminal Panel?
It serves as the interface for connecting discrete digital output signals from Triconex controllers to external field devices. -
How many digital output channels does this terminal panel support?
It supports 6 discrete digital output channels. -
What is the maximum current and voltage rating per channel?
Each channel supports up to 30 V DC and a maximum of 0.5 A current. -
Is the terminal panel compatible with all Triconex safety systems?
Yes, it is designed to integrate smoothly with the entire Triconex safety controller range. -
What kind of terminals does the panel use for wiring?
It uses screw clamp terminals with locking mechanisms to ensure secure connections. -
Can the panel be mounted on DIN rails?
Yes, it supports both DIN rail and panel mounting. -
What certifications does this product have?
It is certified to SIL 3 standards and complies with CE and UL requirements. -
What are the environmental operating limits?
The panel operates reliably in temperatures from -20°C to +70°C and humidity levels from 5% to 95% non-condensing. -
How does this terminal panel aid in system maintenance?
By consolidating output wiring, it simplifies diagnostics and fault isolation. -
Is this panel suitable for hazardous area installation?
It is designed for industrial environments; however, hazardous area suitability depends on the overall system design and enclosures used.
