Product Description
The Triconex CM2201 7400206-100 Communication Baseplate is a high-reliability interface component designed for use within Triconex safety and control systems. It serves as the mounting and interconnection point for communication modules, ensuring stable data transfer and power distribution between system components. The CM2201 is built with industrial-grade materials for durability and operates reliably in demanding process control environments such as oil & gas, petrochemical, and power generation.
Technical Specifications
| Parameter | Value |
|---|---|
| Model Number | CM2201 |
| Part Number | 7400206-100 |
| Type | Communication Baseplate |
| Supported Modules | Triconex communication modules |
| Power Distribution | Integrated bus for module supply |
| Connection Type | Backplane slot connectors |
| Dimensions | 230 × 247 × 42 mm |
| Weight | 1.3 kg |
| Operating Temperature | 0 °C to +60 °C |
| Storage Temperature | -40 °C to +85 °C |
| Mounting Method | Rack/Chassis mount |
| Compliance | Meets Triconex safety system standards |
Applications
The CM2201 is designed for:
-
Process safety systems in oil and gas facilities
-
Distributed control systems in power generation plants
-
Petrochemical plant safety automation
-
Emergency shutdown and fire/gas monitoring systems
-
High-integrity pressure protection systems (HIPPS)
Advantages
-
High Reliability – Engineered for continuous operation in critical safety environments.
-
Robust Construction – Industrial-grade materials resist vibration, dust, and temperature extremes.
-
Optimized Integration – Seamless compatibility with Triconex communication modules.
-
Compact Design – Space-efficient form factor for dense system installations.
-
Stable Data and Power Transfer – Ensures uninterrupted communication and module supply.
FAQ
Q1: What is the function of the CM2201 baseplate?
A1: It provides mounting, communication, and power distribution for Triconex communication modules.
Q2: Is the CM2201 compatible with all Triconex modules?
A2: It is compatible with designated Triconex communication modules as per system configuration.
Q3: Can the CM2201 operate in high-temperature environments?
A3: Yes, it operates between 0 °C and +60 °C.
Q4: Does the CM2201 require special mounting?
A4: It is designed for standard rack or chassis mounting.
Q5: What industries typically use this baseplate?
A5: Oil & gas, petrochemical, power generation, and industrial safety automation.
Q6: How much does the CM2201 weigh?
A6: It weighs 1.3 kg.
Q7: What is the CM2201’s size?
A7: 230 × 247 × 42 mm.
Q8: Is it resistant to vibration and dust?
A8: Yes, it is designed for industrial environments with high durability.
Q9: Does it provide both communication and power distribution?
A9: Yes, it integrates both functions.
Q10: Can it be used in redundant safety configurations?
A10: Yes, it supports configurations in Triconex safety systems.
Related Models (Same Series or Similar)
| Model Number | Description | Dimensions (mm) | Weight |
|---|---|---|---|
| CM2202 | Communication Baseplate | 230 × 247 × 42 | 1.3 kg |
| CM2203 | Communication Baseplate | 230 × 247 × 42 | 1.3 kg |
| CM3201 | Communication Baseplate | 230 × 247 × 42 | 1.3 kg |
| CM3202 | Communication Baseplate | 230 × 247 × 42 | 1.3 kg |
| CM3203 | Communication Baseplate | 230 × 247 × 42 | 1.3 kg |
| CM4201 | Communication Baseplate | 230 × 247 × 42 | 1.3 kg |
