Woodward 5461-648 Transceiver Module

Company Information
E-mail		sales@xmjzjsgs.com
Mobile		+8613666033393
Whatsapp		+8613666033393
WeChat		13666033393
Add		Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China

Product Introduction

The Woodward 5461-648 Transceiver Module is a robust, high-performance communication module designed to ensure reliable data exchange within Woodward turbine and engine control systems. It serves as an essential interface component that converts electrical signals into optical or electrical transmissions for seamless integration with control networks.

Known for its industrial durability, superior signal fidelity, and compatibility with various Woodward control architectures, the 5461-648 Transceiver Module provides critical connectivity in environments subject to harsh electrical noise, temperature fluctuations, and mechanical vibrations.

The module supports high-speed data transmission across serial and networked systems, ensuring the integrity of control commands and feedback signals in real-time process control. Its modular design, combined with advanced diagnostics and rugged build, makes it a preferred choice for OEMs and system integrators in power generation, marine, and process automation sectors.

---

Product Parameters

---

Applications

The Woodward 5461-648 Transceiver Module is engineered for versatile deployment across multiple sectors requiring robust industrial communication solutions:

• Gas and Steam Turbine Control Systems

  • Reliable data interface between controller modules and field devices.

• Engine and Generator Set Control

  • High-integrity communication for load-sharing, synchronization, and governor control.

• Marine Propulsion Control

  • Network interface for shipboard engine and auxiliary controls.

• Oil & Gas Processing

  • High-speed data transmission in hazardous or noisy environments.

• Substation Automation

  • Interfaces between protective relays, RTUs, and SCADA systems.

• Process Automation Networks

  • Integration of legacy equipment with modern digital control architectures.

---

Product Advantages

• High Signal Fidelity
  Converts electrical signals to fiber optic or shielded serial signals, maintaining high data integrity even in noisy environments.

• Flexible Protocol Support
  Compatible with common industrial standards: RS-232, RS-485, and fiber optics.

• Excellent Isolation
  ≥1500 VDC isolation prevents ground loops and enhances system safety.

• Wide Operating Temperature Range
  Designed for extended operation in both high-temperature and arctic conditions.

• Compact Footprint
  Slim, modular design allows dense installation within limited cabinet space.

• LED Diagnostics
  Provides clear status indication for quick troubleshooting and maintenance.

• Industrial-Grade Durability
  Certified to withstand vibration, shock, humidity, and chemical exposure.

• Easy Integration
  Drop-in compatibility with Woodward platforms and many third-party systems.

• Global Approvals
  CE, UL, CSA, and RoHS compliance ensures acceptance in international markets.

• Low Power Consumption
  Operates efficiently to minimize heat dissipation and extend system longevity.

---

FAQ (10 In-Depth Technical Questions and Answers)

1. What is the primary function of the 5461-648 Transceiver Module?
   The module converts electrical signals (RS-232/RS-485) to optical or differential electrical formats for reliable data transmission.

2. Can this module be used in fiber-optic communication networks?
   Yes, the 5461-648 is designed for both fiber-optic and serial communications, depending on configuration.

3. What kind of isolation does the module provide?
   It offers 1500 VDC isolation between input/output and ground, protecting against transient voltage spikes and ground loops.

4. What baud rates are supported?
   Supports baud rates up to 115.2 kbps, suitable for fast serial communication.

5. Is the module hot-swappable?
   Yes, it can be replaced during system operation without requiring a full shutdown.

6. Does it support redundant communication paths?
   The module can be configured to support redundant communication channels, depending on system design.

7. How does the module indicate status?
   LED indicators provide real-time status for power and communication links.

8. Can it interface with legacy equipment?
   Yes, it is compatible with both modern and legacy Woodward control platforms, ensuring easy integration in retrofit projects.

9. Is there support for DIN rail mounting?
   Yes, it can be easily installed on DIN rails or panel-mounted inside control enclosures.

10. What maintenance does this module require?
    Minimal — periodic visual inspection for connector integrity and verification of LED status is typically sufficient.

---
