The Woodward 5463-473 C SIO CPU Module is a high-performance processing and communication module designed for use in Woodward’s MicroNet™ control systems. This CPU module integrates advanced serial I/O (SIO) capabilities, real-time processing, and high-speed data handling to manage complex control tasks in industrial and power generation applications. It serves as the core processor for coordinating input/output operations, executing control algorithms, and enabling seamless communication with other modules within the control rack.
Engineered with robust hardware architecture, the 5463-473 C SIO CPU Module provides deterministic performance, ensuring reliable operation in demanding environments such as turbine control, compressor management, and other mission-critical industrial systems. Its modular design allows easy integration and scalability within Woodward’s distributed control systems.
Product Specifications
| Parameter | Details |
|---|---|
| Product Model | Woodward 5463-473 C SIO CPU Module |
| Product Type | CPU and Serial I/O Module |
| Processor Type | High-performance embedded CPU |
| I/O Support | Serial I/O (multiple RS-232/RS-485 channels) |
| Communication Protocols | Modbus RTU, proprietary Woodward protocols |
| Memory | Onboard RAM and non-volatile flash storage |
| Processing Speed | Real-time deterministic control performance |
| Power Supply Requirement | 24 VDC nominal |
| Operating Temperature | –20°C to +65°C |
| Storage Temperature | –40°C to +85°C |
| Mounting Type | Rack-mounted (MicroNet™ control rack) |
| Compliance Standards | CE, UL, CSA, IEC |
| Diagnostics | Built-in self-test and status monitoring |
| Dimensions (H x W x D) | 228 x 192 x 10 mm |
| Weight | 0.39 kg |
Product Applications
The Woodward 5463-473 C SIO CPU Module is used in various industrial and power generation systems where high-performance control and serial I/O management are required:
-
Turbine Control Systems: Serves as the central processing unit in steam, gas, and hydro turbine control applications.
-
Compressor Management: Manages real-time control and monitoring of industrial compressors.
-
Power Generation Units: Integrates into distributed control systems for generators and auxiliary systems.
-
Industrial Automation: Supports complex process control applications requiring deterministic execution.
-
Communication Gateway: Provides high-speed data exchange between different control subsystems.
-
Retrofit Projects: Ideal for upgrading existing MicroNet™ systems with enhanced CPU and I/O capabilities.
Product Advantages
-
Integrated CPU and I/O: Combines processing power and serial communication in a single module.
-
High Reliability: Built for continuous operation in mission-critical control environments.
-
Fast Data Handling: Optimized for real-time processing and deterministic performance.
-
Scalable Architecture: Easily integrates into existing Woodward MicroNet™ systems.
-
Comprehensive Diagnostics: Built-in self-test and monitoring enhance system reliability.
-
Flexible Communication: Supports multiple serial channels and industrial communication protocols.
FAQ
-
What type of communication interfaces does the 5463-473 C support?
It supports multiple RS-232 and RS-485 serial communication channels for data exchange. -
Is the 5463-473 C compatible with existing MicroNet™ racks?
Yes, it is fully compatible with standard Woodward MicroNet™ control racks. -
Does the CPU module support Modbus communication?
Yes, it supports Modbus RTU as well as proprietary Woodward communication protocols. -
What is the primary function of the SIO CPU Module?
It acts as the central processing unit, handling control logic execution and managing serial I/O operations. -
Can the 5463-473 C be used in redundant configurations?
Yes, it supports redundant CPU configurations for high-availability control systems. -
What diagnostic features are included?
The module includes built-in self-tests, health status monitoring, and communication diagnostics. -
What type of power supply does the module require?
It operates on a nominal 24 VDC power supply input. -
What are the typical industrial applications of the 5463-473 C?
It is primarily used in turbine control, compressor management, and power generation control systems. -
Does the CPU module support firmware upgrades?
Yes, it supports in-system firmware updates through secure channels. -
Is the 5463-473 C designed for harsh environments?
Yes, it is built to meet industrial environmental standards with wide temperature tolerance and EMI protection.
