Product Introduction
The Woodward 5466-253 Analog Combo Module is an advanced, high-performance control module designed to meet the needs of industrial control applications. Manufactured by Woodward, a leader in energy control solutions, this module is part of their suite of versatile products used in engine and turbine control systems. The 5466-253 is specifically engineered to integrate analog input and output signals for precise control of power generation systems, providing enhanced reliability, flexibility, and ease of use.
This analog combo module is equipped with multiple channels for analog input and output, making it an ideal solution for applications requiring precise monitoring and adjustment of system parameters such as speed, load, and pressure. It is designed to work seamlessly within Woodward’s controls platforms, making it easy to integrate into existing control systems without the need for significant modifications. The module supports various industrial communication protocols, ensuring compatibility with a wide range of systems.
The Woodward 5466-253 module is widely used in power generation plants, industrial engines, and turbine systems, where it performs critical roles in monitoring and controlling vital engine parameters, enhancing overall system performance.
Product Specifications
| Parameter | Specification |
|---|---|
| Model Number | 5466-253 |
| Manufacturer | Woodward |
| Product Type | Analog Combo Module |
| Input Signal | Analog signals (0-10 V, 4-20 mA) |
| Output Signal | Analog output (0-10 V, 4-20 mA) |
| Power Supply | 24 V DC |
| Mounting Type | DIN Rail or Panel Mount |
| Dimensions (H x W x D) | 180 x 120 x 80 mm |
| Weight | 0.839 kg |
| Operating Temperature | -40°C to +70°C |
| Humidity | 0% to 95% RH (non-condensing) |
| Communication Protocol | Modbus RTU, CANopen, or proprietary Woodward protocols |
| Control Type | Analog control with feedback capability |
| Enclosure Rating | IP20 (dust protected) |
| Certification | CE, UL, RoHS Compliant |
| Application | Power generation, turbine and engine control |
| Protection Features | Overvoltage, undervoltage, overcurrent protection |
| Signal Conditioning | Built-in signal filtering and amplification |
| Status Indicators | LED indicators for status and fault detection |
| Calibration | Factory-calibrated with adjustable parameters |
Product Applications
The Woodward 5466-253 Analog Combo Module is designed for use in various industrial applications where reliable analog control is essential. Key applications include:
-
Power Generation: It is widely used in power generation plants for controlling the speed, load, and fuel injection in turbines and engines, ensuring stable power output.
-
Industrial Engines: The module is used to monitor and control engines in industries such as oil and gas, mining, and manufacturing, providing accurate control of speed and power.
-
Turbine Systems: In gas, steam, or wind turbines, the 5466-253 module optimizes turbine performance by adjusting key parameters based on real-time data.
-
Renewable Energy: It is also used in renewable energy plants such as wind and solar farms to monitor energy generation and control electrical output.
-
Marine Applications: The module is used in marine engines and propulsion systems, ensuring efficient and reliable control of engine speeds and fuel consumption.
Product Advantages
-
High Flexibility: With support for both analog input and output signals, the Woodward 5466-253 is highly adaptable to different control systems, enhancing the flexibility of integration into existing systems.
-
Compact and Durable Design: The module is housed in a compact, rugged enclosure, capable of withstanding challenging industrial environments with protection against dust and moisture (IP20 rated).
-
Accurate Control: Provides high-precision analog control for a variety of system parameters such as speed, load, and pressure, optimizing the overall performance of the system.
-
Broad Compatibility: The module supports multiple communication protocols including Modbus RTU and CANopen, making it compatible with various control systems.
-
Easy Integration: Designed for easy mounting on DIN rails or panels, and offers seamless integration with Woodward’s control platforms and third-party systems.
-
Energy Efficient: Low power consumption ensures that it operates efficiently while reducing the overall energy usage of the system.
-
Advanced Diagnostics: Equipped with diagnostic LEDs and status indicators, making fault detection quick and easy, which reduces system downtime.
-
Customizable Settings: The module’s calibration and configuration settings can be easily adjusted to suit specific application requirements, offering a high level of customization.
Frequently Asked Questions (FAQ)
-
Q: What is the main function of the Woodward 5466-253 Analog Combo Module?
A: The primary function is to provide precise control and monitoring of industrial engines and turbines by processing analog input and output signals. -
Q: What is the input range of the module?
A: The module supports 0-10 V and 4-20 mA analog input signals. -
Q: Can the Woodward 5466-253 be used with multiple engines?
A: Yes, the module is highly versatile and can be used with various engine types in different industries. -
Q: What are the communication protocols supported by this module?
A: The module supports Modbus RTU, CANopen, and proprietary Woodward communication protocols. -
Q: What are the mounting options for the 5466-253 module?
A: The module can be mounted on a DIN rail or directly on a panel. -
Q: Is the Woodward 5466-253 module suitable for use in harsh environments?
A: Yes, it is built to operate in industrial environments, with an IP20 enclosure rating to protect against dust and moisture. -
Q: How can I calibrate the Woodward 5466-253 module?
A: The module comes factory-calibrated, but it also allows for adjustable parameters to meet specific requirements. -
Q: What types of engines or turbines can the module control?
A: The module can control a wide range of engines and turbines, including those used in power generation, marine applications, and industrial systems. -
Q: What is the temperature range in which the module operates?
A: The operating temperature range for the Woodward 5466-253 module is -40°C to +70°C. -
Q: What certifications does the module have?
A: The module is certified for CE, UL, and RoHS compliance.
Related Models in the Same Series
| Model Number | Description | Compatibility |
|---|---|---|
| 5466-250 | Analog input module with digital output | Woodward control systems |
| 5466-254 | Analog output module for enhanced engine control | Woodward engine control systems |
| 5466-255 | High-speed analog combo module with feedback capabilities | Woodward turbine control systems |
| 5466-260 | Compact analog combo module with extended input ranges | Woodward systems |
| 5466-257 | Modular analog interface for customized applications | Woodward industrial engines |
| 5466-258 | Analog signal conditioning module | Woodward power systems |
Popular Models from the Same Brand (Woodward)
| Model Number | Description | Application |
|---|---|---|
| Woodward 505 | Digital Governor for turbine and engine control | Power Generation |
| Woodward 2301D | Digital controller for gas and steam turbines | Power Generation, Oil & Gas |
| Woodward 2301E | Enhanced controller for advanced turbine systems | Energy Generation |
| Woodward 1117 | Generator and engine control system | Marine, Industrial Engines |
| Woodward MicroNet | Control system for complex power and turbine applications | Turbines, Power Generation |
| Woodward PMD | Programmable digital controller for industrial applications | Industrial Automation |
