The Woodward 5501‑467 Power Supply Board is an industrial-grade module designed to deliver reliable and stable power to control and monitoring systems within critical automation environments. It is engineered to meet the demands of high-performance applications by providing regulated voltage, protective features, and seamless integration into Woodward platforms. With robust construction and high efficiency, the 5501‑467 ensures the operational stability of mission-critical systems.
Key Features
-
Regulated power output for consistent system operation
-
High-performance reliability for industrial applications
-
Over-voltage and over-current protection
-
Designed for long service life in harsh environments
-
Compact board layout for space-limited enclosures
-
Ideal for use in Woodward control systems
Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | 5501‑467 |
| Module Type | Power Supply Board |
| Input Voltage Range | 18–32 VDC |
| Output Voltage | Typically 5 VDC / 12 VDC (application-dependent) |
| Output Current | As per system load requirements |
| Protection | Over-voltage, over-current, thermal protection |
| Status Indicators | Integrated status diagnostics (if applicable) |
| Dimensions | 180 × 120 × 25 mm |
| Weight | 0.6 kg |
| Mounting Style | Internal board installation |
| Operating Temperature | –40 °C to +70 °C |
| Designed For | Woodward control and automation systems |
| Country of Manufacture | United States of America |
