Woodward 8406-113 Control Operator Interface

Product Introduction

The Woodward 8406-113 Control Operator Interface (COI) is a specialized human-machine interface (HMI) designed for use with Woodward control systems in industrial and power generation applications. It serves as the main user interaction point, providing operators with clear, real-time access to system parameters, alarms, and control functions.

Engineered for durability and reliability, the 8406-113 integrates seamlessly with Woodward turbine, engine, and process controllers. It ensures intuitive operation through a combination of display elements, keypad functions, and communication capabilities. By offering a central point of control and monitoring, the 8406-113 reduces system complexity and enhances operational efficiency.


Product Specifications

Parameter Specification
Model Number 8406-113
Type Control Operator Interface (COI)
Compatible Systems Woodward turbine and engine control platforms
Power Supply 24 VDC nominal
Display Type LCD graphical display with backlight
Interface Keypad navigation, status LEDs, programmable keys
Communication Protocols RS-232, RS-485, Modbus, proprietary Woodward link
Alarm Handling Multi-level alarm indication and acknowledgement
Event Logging Stores alarms, events, and operating data
Operating Temperature -20°C to +70°C
Storage Temperature -40°C to +85°C
Relative Humidity 5% – 95%, non-condensing
Mounting Type Panel-mounted
Dimensions (HxWxD) 220 x 160 x 60 mm
Weight 4.08 kg

Product Applications

The 8406-113 COI is widely used in industrial automation and power generation environments, where operator access to system status and control functions is critical. Main applications include:

  • Turbine control systems (steam, gas, and hydro turbines)

  • Engine management in power generation and marine propulsion

  • Compressor and pump control in petrochemical and process industries

  • Distributed control systems where localized operator panels are required

  • Emergency and backup power systems for rapid operator interaction

  • Industrial process automation where human oversight is required in harsh environments


Product Advantages

The Woodward 8406-113 COI provides several advantages that make it a dependable choice for industrial operators:

  • User-Friendly Operation: Intuitive keypad and display layout minimize operator training.

  • Reliable Communication: Supports multiple protocols, enabling flexible system integration.

  • Robust Design: Built for operation in challenging environments, with wide temperature tolerance.

  • Efficient Alarm Management: Provides clear alarm indicators, helping operators respond quickly.

  • Event Logging Capability: Keeps a record of historical data, aiding in troubleshooting.

  • Seamless Integration: Fully compatible with Woodward controllers, ensuring plug-and-play setup.

  • Reduced Downtime: Simplifies diagnostics, reducing mean time to repair (MTTR).


Frequently Asked Questions (FAQ)

  1. Which communication protocols are supported by the 8406-113 interface?
    It supports RS-232, RS-485, Modbus, and proprietary Woodward communication links.

  2. Can the interface handle simultaneous communication with multiple controllers?
    Yes, depending on configuration, it can manage communication across multiple control channels.

  3. How does the 8406-113 display alarm notifications?
    Alarms are shown on the LCD display with priority levels and supported by LED indicators.

  4. Is the interface capable of logging system events?
    Yes, it records alarms, operator actions, and events for later review.

  5. Does the 8406-113 allow configuration changes to the control system?
    Yes, authorized operators can adjust setpoints and parameters directly via the keypad.

  6. How does the COI maintain reliable communication in noisy industrial environments?
    It uses isolated serial communication ports and robust error-checking protocols.

  7. Is the interface firmware upgradeable?
    Yes, firmware updates can be applied to maintain compatibility and add features.

  8. What happens if communication with the controller is lost?
    The COI generates a communication fault alarm and retains the last valid displayed data.

  9. Can the 8406-113 be integrated into redundant system configurations?
    Yes, it supports redundant communication channels and can operate in high-availability systems.

  10. How does the COI ensure security against unauthorized access?
    It provides operator-level password protection and configurable access privileges.


Related or Series Models

Model Number Description
8406-111 COI with basic communication features
8406-112 Advanced COI with extended logging capability
8406-114 Ruggedized COI for harsh environments
8406-115 High-contrast COI with enhanced display
8406-116 Multi-protocol COI with Ethernet support
8406-117 COI with touchscreen operation

Popular Models from the Same Brand

Model Number Description
