Woodward 8440-1809 Control Panel

Product Introduction

The Woodward 8440-1809 Control Panel is an advanced control interface designed to integrate seamlessly with Woodward turbine and engine control systems. This panel acts as the primary human-machine interface (HMI) for operators, providing monitoring, configuration, and control functions for a wide range of industrial applications.

Built with robust hardware and intuitive software, the 8440-1809 allows real-time visualization of system parameters, alarm handling, and operational adjustments. Its modular design ensures adaptability for different control strategies, while its rugged industrial build guarantees long-term reliability in harsh operating environments such as power plants, petrochemical facilities, and marine systems.

Product Specifications

Applications

The Woodward 8440-1809 Control Panel is versatile and widely used in industries requiring precision monitoring and operator control:

• Power Generation Plants – Provides operators with complete turbine, generator, and auxiliary equipment monitoring.

• Oil & Gas – Used for compressor control, drilling rigs, and gas turbine operation.

• Petrochemical Industry – Enables process control adjustments and alarm handling for critical systems.

• Marine Industry – Integrates with propulsion and auxiliary control systems for safe vessel operation.

• Industrial Manufacturing – Interfaces with plant control systems for monitoring motors, drives, and automated processes.

• Renewable Energy – Supports wind and hydro plant control by providing operators with a stable HMI platform.

Advantages

The 8440-1809 Control Panel offers several technical and operational benefits:

• User-Friendly Interface – Clear graphical display and intuitive controls simplify operator interaction.

• Robust Communication – Multiple communication ports and supported protocols ensure wide compatibility.

• High Reliability – Industrial-grade design ensures stable performance in harsh environments.

• Event Logging – Built-in memory stores alarm and event history for diagnostics.

• Flexible Integration – Compatible with various Woodward control systems and external networks.

• Enhanced Protection – Surge and polarity protection reduce risk of damage during power fluctuations.

• Scalable System Use – Can be deployed in single-engine or multi-unit plant configurations.

Frequently Asked Questions (FAQ)

1. Which communication protocols are supported by the 8440-1809 Control Panel?
   Supported protocols include Modbus TCP/IP, Modbus RTU, and CANopen.

2. How does the panel connect with Woodward controllers?
   It interfaces via Ethernet, RS-232, RS-485, or CANbus connections.

3. Does the panel support data logging?
   Yes, it provides storage for alarm history and event logs.

4. What is the nominal power supply requirement?
   The panel operates on a nominal 24 VDC supply.

5. How are operator inputs handled on this panel?
   Inputs are managed through a keypad, function buttons, and rotary controls.

6. What type of display does the 8440-1809 use?
   It is equipped with a high-resolution graphical LCD display for real-time monitoring.

7. Can this panel operate in redundant control system configurations?
   Yes, it can integrate into redundant setups for high-availability systems.

8. What diagnostic features are available?
   The panel includes built-in self-tests, system error reporting, and LED status indicators.

9. Is the control panel compatible with marine environments?
   Yes, it carries marine certifications and is designed for harsh maritime conditions.

10. How does the panel communicate system alarms to operators?
    Alarms are displayed on the LCD interface and logged in the event history for review.
