Yokogawa AAV144-S53/K4A00 Voltage Input Module

Manufacturer:Yokogawa

Product Number:AAV144-S53/K4A00

Product Type:Voltage Input Module

Origin:Japan

Dimensions:107.5 × 130 × 32.8 mm

Weight:0.2 kg

Views:123

Payment Methods:T/T, PayPal, Western Union

Condition:New & In Stock

Shipping Port:Xiamen, China

Warranty:1 Year

Lead Time:1-3 Working Days

Certificate:COO

Courier partners:DHL, UPS, TNT, FedEx and EMS.

Business hours:7*24


  • Product Details
  • FAQs
  • Related
  • Contact Us
  • Packing & Delivery
  • Product Ratings
Company Information
E-mail [email protected]
Mobile +8613666033393
Whatsapp +8613666033393
WeChat 13666033393
Add Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China

Yokogawa AAV144-S53/K4A00 Voltage Input Module

Product Introduction

The Yokogawa AAV144-S53/K4A00 is a high-performance Voltage Input Module designed specifically for integration with Yokogawa’s CENTUM CS 3000 and CENTUM VP distributed control systems (DCS). As part of the Analog Input Module family, this model excels in monitoring DC voltage signals, delivering precision analog measurements for complex industrial automation systems. Its robust configuration allows for enhanced signal fidelity, low-noise performance, and high immunity to electrical interference, making it a reliable component for critical process applications.

Developed with long-term reliability and operational continuity in mind, the AAV144-S53/K4A00 supports a wide range of analog voltage signals and is capable of isolating input signals to prevent system-wide disruptions. It is especially tailored for industries requiring strict analog performance, such as power generation, petrochemical, oil and gas, and pharmaceuticals.


Product Specifications

Parameter Description
Model Number AAV144-S53/K4A00
Product Type Voltage Input Module
Manufacturer Yokogawa Electric Corporation
Input Channels 16 channels (isolated per channel)
Input Signal Range ±10V DC (can be configured)
Input Impedance ≥10 MΩ
Resolution 16-bit A/D conversion
Accuracy ±0.1% of full scale
Isolation 1000 V AC between input and system
Conversion Time 50 ms per channel
Power Supply Supplied through the I/O base plate
Diagnostic Function Open wire detection, Input signal failure detection
Redundancy Support Yes (with redundant systems)
Operating Temperature Range 0 to 50°C
Storage Temperature Range -20 to 70°C
Humidity 5% to 95% RH (non-condensing)
Mounting Mounted on I/O base unit
Dimensions (W x H x D) 107.5 × 130 × 32.8 mm
Weight 0.2 kg
Applicable Systems CENTUM CS 3000, CENTUM VP
Certification CE, UL, CSA compliant

Product Applications

  • Oil & Gas: Monitoring of field instruments and control signals in refineries and pipelines.

  • Power Plants: Voltage sensing for turbine control and electrical distribution systems.

  • Pharmaceuticals: Recording cleanroom sensor data with high accuracy.

  • Chemical Processing: Handling analog process variables with minimized signal distortion.

  • Water Treatment: Accurate measurement of control voltages in dosing and filtration systems.

  • Pulp and Paper: Integration into distributed control networks for energy and quality control.


Product Advantages

  • High Signal Accuracy: With 16-bit resolution and low error tolerance, it ensures accurate analog input readings.

  • Input Isolation: Each input channel is isolated, enhancing safety and preventing cross-interference.

  • Advanced Diagnostics: Equipped with failure detection features to support proactive maintenance.

  • System Compatibility: Seamlessly integrates into Yokogawa’s flagship DCS platforms.

  • Reduced Downtime: Supports redundancy configurations to maintain system availability.

  • Space Efficient Design: Compact module suitable for high-density I/O cabinets.

  • Electromagnetic Immunity: Excellent performance in noisy industrial environments.

  • Extended Temperature Range: Reliable operation even in demanding environmental conditions.

  • Compliant with Global Standards: CE, UL, CSA certifications ensure worldwide deployment capabilities.

  • Long-Term Support: Backed by Yokogawa’s extensive service and upgrade lifecycle management.
