Product Introduction
The Yokogawa ADV151-P10/D5A00 Digital Input Module is a high-performance, industrial-grade input module designed for reliable acquisition of digital signals in distributed control systems (DCS). As part of the Yokogawa CENTUM series, this module ensures seamless integration with process automation architectures, delivering stable and accurate digital signal processing under harsh industrial environments. It is engineered with advanced noise immunity, fast response times, and robust isolation features to ensure optimal performance in critical control applications.
Built with a modular architecture, the ADV151-P10/D5A00 allows easy installation, maintenance, and system expansion. The module is suitable for a wide range of industries, including oil & gas, petrochemical, power generation, and manufacturing, where precise digital input monitoring is essential for safety and operational efficiency.
Product Parameters
| Parameter | Specification |
|---|---|
| Manufacturer | Yokogawa |
| Model Number | ADV151-P10/D5A00 |
| Module Type | Digital Input Module |
| Input Channels | 16 channels |
| Input Type | Dry contact or voltage input |
| Input Voltage Range | 24 VDC nominal (typical) |
| Input Current | ≤ 7 mA per channel |
| Isolation | Optical isolation between field and logic |
| Response Time | ≤ 5 ms |
| Power Supply Voltage | 5 VDC (supplied from base unit) |
| Power Consumption | Approx. 3 W |
| Operating Temperature | 0°C to 50°C |
| Storage Temperature | -20°C to 70°C |
| Humidity | 5–95% RH (non-condensing) |
| Mounting | Plug-in module |
| Certifications | CE, CSA, UL |
| Dimensions (W × H × D) | 107.5 × 130 × 32.8 mm |
| Weight | 0.3 kg |
Product Applications
The Yokogawa ADV151-P10/D5A00 is widely used in industries requiring dependable digital signal acquisition. Typical applications include:
-
Process Automation Systems – Capturing field signals from switches, relays, and other digital devices in process plants.
-
Safety Instrumented Systems (SIS) – Monitoring safety-critical inputs for emergency shutdown systems.
-
Power Generation – Input monitoring for turbine control, generator protection, and substation automation.
-
Oil & Gas – Digital monitoring of valves, pumps, and compressor systems.
-
Manufacturing Automation – Real-time monitoring of production lines and machine status.
-
Water Treatment – Supervising pump operation, level switches, and alarm contacts.
Product Advantages
-
High Reliability – Designed for 24/7 industrial operation with minimal downtime.
-
Fast Response Time – Ensures accurate detection of rapid signal changes.
-
Strong Noise Immunity – Reliable operation in electrically noisy environments.
-
Optical Isolation – Protects control logic from voltage spikes and transients.
-
Compact Design – Saves panel space and simplifies installation.
-
Easy Maintenance – Hot-swappable design for quick replacement without shutting down the system.
-
Long Service Life – Industrial-grade components for extended operational use.
FAQ
1. How many digital input channels does the ADV151-P10/D5A00 support?
It supports 16 isolated digital input channels.
2. What type of signals can this module receive?
It can receive dry contact or 24 VDC voltage signals from field devices.
3. What is the typical input voltage for this module?
The nominal input voltage is 24 VDC.
4. Does it have channel-to-channel isolation?
Yes, it uses optical isolation between the input channels and control logic.
5. What is the module’s input response time?
The typical input response time is ≤ 5 milliseconds.
6. Is this module compatible with all Yokogawa CENTUM systems?
Yes, it is designed to integrate seamlessly with CENTUM VP and CS 3000 series systems.
7. Can the module be hot-swapped during operation?
Yes, it supports hot-swapping without system shutdown.
8. What kind of diagnostic functions does it offer?
It supports channel status indication and fault detection for input failures.
9. Does it require an external power supply for field inputs?
Yes, external 24 VDC supply is required for voltage input configurations.
10. Can this module operate in high humidity environments?
Yes, it can operate in up to 95% RH non-condensing environments.
Related Models (Same Series or Similar Function)
| Model Number | Description |
|---|---|
| ADV151-P10/D5A00 | 16-channel digital input module |
| ADV151-P50/D5A00 | High-performance digital input module with enhanced diagnostics |
| ADV151-S00/D5A00 | Digital input module for safety instrumented systems |
| ADV151-E10/D5A00 | Extended temperature range digital input module |
| ADV161-P10/D5A00 | 32-channel digital input module |
| ADV141-P10/D5A00 | 8-channel digital input module for low-density applications |
Popular Yokogawa Modules
| Model Number | Description |
|---|---|
| ADV551-P00/D5A00 | Digital output module, 16 channels |
| ADV151-P10/D5A00 | Digital input module, 16 channels |
| AAI141-S50/D5A00 | Analog input module, 16 channels |
| AAI143-S00/D5A00 | High-speed analog input module |
| AAD143-S00/D5A00 | Analog output module, 8 channels |
| ADV161-P50/D5A00 | High-density digital input module, 32 channels |
