Product Introduction
The Yokogawa ADV151-P50 is a rugged and reliable digital input module designed to serve as a key component in Yokogawa’s advanced distributed control systems (DCS), such as the CENTUM VP platform. This module is tailored to provide stable and accurate acquisition of digital signals from field devices, enabling precise monitoring and control in demanding industrial environments.
Engineered for high availability and fault tolerance, the ADV151-P50 supports a wide range of discrete input signals, including dry contact and NAMUR sensors. Its robust construction and advanced diagnostics make it a preferred choice in process automation industries where uptime and safety are paramount. This module is essential for operators who require real-time digital signal status to make critical operational decisions.
Product Specifications
| Parameter | Specification |
|---|---|
| Model Number | ADV151-P50 |
| Module Type | Digital Input Module |
| Number of Input Channels | 16 |
| Input Signal Type | Dry contact, NAMUR sensor |
| Input Voltage | 24 V DC nominal |
| Response Time | ≤ 10 milliseconds |
| Isolation Voltage | 1500 Vrms (channel to system) |
| Power Consumption | Approx. 4.0 W |
| Operating Temperature | 0 to 55°C (32 to 131°F) |
| Storage Temperature | -20 to 70°C (-4 to 158°F) |
| Humidity | 5% to 95% RH, non-condensing |
| Dimensions (H x W x D) | 107.5 × 130 × 32.8 mm |
| Weight | 0.3 kg |
| Mounting Type | Rack-mounted |
Product Applications
-
Chemical and Petrochemical Plants: Monitoring discrete signals from pumps, valves, and safety interlocks to ensure smooth and safe process operations.
-
Power Generation: Tracking turbine statuses, breaker conditions, and alarm inputs to maintain continuous and reliable power output.
-
Water Treatment Facilities: Digital input acquisition from level switches, flow indicators, and pump operation signals for effective water management.
-
Oil and Gas Industry: Capturing status information from wellhead equipment, emergency shutdown systems, and process interlocks on platforms and refineries.
-
Manufacturing: Integration of digital signals from production machinery, conveyor belts, and quality control sensors to optimize throughput and reduce downtime.
-
Building Automation: Handling inputs from security systems, HVAC controls, and lighting systems to enhance building operational efficiency.
Product Advantages
-
High Reliability: Designed for continuous operation in harsh industrial environments, ensuring consistent digital signal acquisition.
-
Fast and Accurate Response: Input signals are processed within 10 milliseconds, enabling real-time monitoring and control.
-
Strong Electrical Isolation: 1500 Vrms isolation protects the system from electrical noise and transient disturbances.
-
Compact and Modular: Space-efficient design allows for easy installation and system expansion without major cabinet redesign.
-
Broad Environmental Tolerance: Operates reliably over a wide temperature and humidity range suitable for many industrial sites.
-
Energy Efficiency: Low power consumption reduces operational costs and heat generation within control cabinets.
-
Advanced Diagnostics: Integrated diagnostics assist maintenance teams in quickly identifying faults and maintaining system uptime.
-
Seamless System Integration: Fully compatible with Yokogawa CENTUM VP and related DCS platforms, simplifying configuration and operation.
-
Proven Field Performance: Widely used in various industries with a strong reputation for durability and performance.
-
Support and Service: Backed by Yokogawa’s global technical support and service network for lifecycle support and spare parts availability.
Frequently Asked Questions (FAQ)
-
What digital input types are supported by the ADV151-P50?
It supports dry contact inputs and NAMUR sensor inputs, common in industrial control systems. -
How many input channels does the module have?
The module includes 16 individual digital input channels. -
Is this module compatible with other Yokogawa systems?
Yes, it integrates seamlessly with Yokogawa CENTUM VP and other Yokogawa DCS systems. -
What is the power consumption of the ADV151-P50?
The module consumes 4.0 watts during operation. -
Can the module operate in electrically noisy environments?
Yes, it provides 1500 Vrms electrical isolation to protect against noise and surges. -
What is the response time for signal changes?
Input changes are detected and processed within 10 milliseconds. -
How is the module installed?
It is designed for rack mounting within standard Yokogawa system racks. -
What are the operating temperature limits?
The module is rated for operation between 0 to 55°C (32 to 131°F). -
Does the module have self-diagnostic features?
Yes, built-in diagnostics allow monitoring of input channel status and module health. -
Is the module certified for use in hazardous areas?
While the module is typically installed in safe control rooms, it is not intrinsically safe by itself.
Related Models from Yokogawa ADV Series
| Model Number | Module Type | Input Channels | Operating Temperature | Notes |
|---|---|---|---|---|
| ADV151-P10 | Digital Input Module | 16 | 0 to 55°C | Standard digital input module |
| ADV151-P20 | Digital Input Module | 32 | 0 to 55°C | Higher channel density |
| ADV152-P10 | Digital Output Module | 16 | 0 to 55°C | Digital output counterpart |
| ADV153-P10 | Analog Input Module | 8 | 0 to 55°C | For analog sensor inputs |
| ADV154-P10 | Analog Output Module | 8 | 0 to 55°C | Analog control signals output |
| ADV155-P10 | Digital Input Module | 16 | -20 to 60°C | Wider temperature range |
Popular Yokogawa Models (Same Brand)
| Model Number | Description | Typical Application |
|---|---|---|
| CENTUM VP | Distributed Control System | Integrated process automation |
| ProSafe-RS | Safety Instrumented System | Process safety and shutdown |
| ADV151-P30 | High-Density Digital Input Module | Complex digital monitoring |
| YTA610 | Temperature Transmitter | Accurate temperature measurement |
| YHC620 | Digital Controller | Loop and valve control |
| DPharp EJA Series | Differential Pressure Transmitter | Process pressure monitoring |
