Yokogawa ADV169-P01 Digital Input Module

Yokogawa/

Yokogawa ADV169-P01 Digital Input Module

Manufacturer:Yokogawa

Product Number:ADV169-P01

Product Type:Digital Input Module

Origin:Japan

Dimensions:130 x 127.2 x 32.8 mm

Weight:0.3 kg

Views:27

Payment Methods:T/T, PayPal, Western Union

Condition:New & In Stock

Shipping Port:Xiamen, China

Warranty:1 Year

Lead Time:1-3 Working Days

Certificate:COO

Courier partners:DHL, UPS, TNT, FedEx and EMS.

Business hours:7*24


  • Product Details
  • FAQs
  • Related
  • Contact Us
  • Packing & Delivery
Company Information
E-mail sales@xmjzjsgs.com
Mobile +8613666033393
Whatsapp +8613666033393
WeChat 13666033393
Add Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China

Product Introduction

The Yokogawa ADV169-P01 is a high-density 32-channel digital input module designed for integration into Yokogawa’s CENTUM VP and ProSafe-RS control systems. Engineered to collect discrete signals from field devices such as limit switches, pushbuttons, contactors, and safety interlocks, this module is a critical component for reliable and real-time digital input processing in complex industrial systems.

This module is part of the Fieldbus I/O (FIO) family and offers enhanced input signal diagnostics and robust isolation features. The ADV169-P01 is designed to accept non-polarized voltage inputs, ensuring flexibility in wiring and reducing engineering effort during system setup. With optical isolation for each channel and configurable input filter times, the module ensures accurate detection of state changes, while suppressing electrical noise from the field.

The ADV169-P01 is well-suited for applications that require high-speed monitoring, accurate event timestamping, and integration into both standard and safety instrumented systems. It is especially ideal for demanding sectors such as oil & gas, chemical processing, power generation, and large-scale manufacturing.


Product Specifications

Parameter Specification
Model Number ADV169-P01
Function 32-Channel Digital Input Module
Input Channels 32 channels
Input Signal Type Voltage input, non-polarized
Nominal Input Voltage 24 VDC (operating range: 18–30 VDC)
Input Current Approximately 6 mA per channel
Input Filter Times Configurable: 3 ms, 10 ms, 20 ms, 100 ms
Sequence of Events (SOE) Supported with 1 ms timestamp accuracy
Input Isolation Optical isolation per channel
Internal Power Supply Supplied via system backplane
Power Consumption Approx. 5.5 W
Mounting Method Baseplate mounting
Terminal Connection Removable screw-type terminal block
Communication Interface FIO (Fieldbus I/O)
Operating Temperature 0 to +55 °C
Storage Temperature -20 to +70 °C
Humidity Tolerance 5% to 95% RH (non-condensing)
Vibration Resistance 10 to 60 Hz, 0.7 mm amplitude
Shock Resistance 10 G
Dimensions 130 x 127.2 x 32.8 mm
Weight 0.3 kg
Certifications CE, ATEX, CSA (varies by configuration)
Hot-Swap Capability Supported
Wiring Type Non-polarized signal wiring

Product Applications

  • Process Safety Systems: The ADV169-P01 is widely used in SIS (Safety Instrumented Systems) to acquire safety-critical digital input signals such as emergency shutdown initiators, fire and gas detectors, and fault alarms.

  • Oil & Gas Platforms: Ideal for collecting contact inputs from motor starters, pressure switches, valve limit switches, and local control panels in hazardous offshore and onshore environments.

  • Chemical Processing Plants: Handles extensive I/O in batch, continuous, and hybrid chemical systems where contact input state accuracy and fast detection are crucial.

  • Power Generation Facilities: Used in turbine control systems and auxiliary monitoring where digital inputs from field relays and interlocks must be monitored continuously and precisely.

  • Water Treatment Systems: Efficiently interfaces with flow switches, pressure switches, level switches, and door interlocks in water and wastewater automation.

  • Manufacturing Automation: Supports the acquisition of interlock signals, safety relay feedback, emergency stop button signals, and machine status feedback.


Product Advantages

  • High-Density Input Capability: 32 digital input channels in a single module maximize space efficiency and reduce installation footprint.

  • Non-Polarized Wiring: Simplifies field wiring by accepting signals without regard to polarity, reducing installation errors.

  • Advanced SOE Logging: Integrated Sequence of Events capability provides accurate timestamping for incident reconstruction and root cause analysis.

  • Optical Isolation Per Channel: Each input is isolated from system electronics and other channels to protect against voltage spikes and ground loops.

  • Hot-Swappable Design: Enables maintenance and replacement without shutting down the system, minimizing operational disruptions.

  • Wide Operating Range: Built to operate in harsh industrial conditions with wide temperature and humidity tolerances.

  • Selectable Input Filtering: Adjustable input debounce times help to eliminate false signal readings due to contact bounce or field noise.

  • Integrated Diagnostics: Provides channel-level diagnostics for input signal status, aiding in rapid troubleshooting.

  • Standard Compliant: Compatible with international standards for use in critical applications including hazardous areas.

  • Backed by Yokogawa Reliability: Engineered under Yokogawa’s rigorous quality standards, ensuring durability and system integrity.


Frequently Asked Questions (FAQ)

  1. Q: What is the difference between ADV169-P01 and ADV169-P00?
    A: The ADV169-P01 is an enhanced variant with improved SOE support and diagnostics over the P00 version.

  2. Q: Does the module support hot-swapping?
    A: Yes, the ADV169-P01 can be replaced without system shutdown when configured properly.

  3. Q: What input signal types are supported?
    A: The module accepts 24 VDC non-polarized digital voltage inputs.

  4. Q: Can this module be used in ProSafe-RS systems?
    A: Yes, it is designed to be fully compatible with Yokogawa’s ProSafe-RS SIS platform.

  5. Q: What is the maximum cable length for input wiring?
    A: It depends on wire gauge and field noise, but typically up to 500 meters with proper shielding.

  6. Q: Is Sequence of Events logging supported?
    A: Yes, with timestamp resolution up to 1 millisecond.

  7. Q: What terminal type is used for wiring?
    A: The module uses a removable screw-type terminal block for secure and convenient connections.

  8. Q: What are the dimensions of the ADV169-P01?
    A: 130 x 127.2 x 32.8 mm

  9. Q: How much does the module weigh?
    A: 0.3 kg.

  10. Q: Is this module suitable for use in hazardous zones?
    A: Yes, certain configurations are certified for use in ATEX and CSA hazardous environments.


Related Models (Same Series or Function)

Model Description Channels Type SOE
ADV169-P00 32-Channel Digital Input Module 32 Digital Input Yes
ADV161-P50 16-Channel Digital Input Module 16 Digital Input Yes
ADV151-P00 8-Channel Digital Input Module 8 Digital Input No
ADV561-P00 32-Channel Digital Output Module 32 Digital Output N/A
ADV551-P00 8-Channel Digital Output Module 8 Digital Output N/A
ADV171-P50 64-Channel DI/DO Mixed Module 64 (32 IN/32 OUT) Digital I/O Partial

Popular Yokogawa Modules (Same Brand)

Model Description Type System Channels
CP471-10 Dual CPU Control Processor Controller CENTUM VP N/A
AAI141-H50 High-Speed Analog Input Module Analog Input CENTUM VP 16
AAI543-H00 Analog Output Module Analog Output CENTUM VP 8
AAR181-S00 RTD Input Module Temperature Input CENTUM VP 8
ALR121-S00 Alarm Relay Output Module Relay Output Alarms 8
PW482-10 System Power Supply Unit Power Module CENTUM VP N/A
