Yokogawa ADV551-P03 S2 Digital Output Module

Product Introduction

The Yokogawa ADV551-P03 S2 Digital Output Module is a critical component of the Yokogawa CENTUM VP control system’s Network Input/Output (N-IO) platform. This module is designed for precise and reliable digital output control in various industrial automation environments. It supports discrete output signals to operate field devices such as solenoids, relays, and motor starters.

This second-generation (S2) module enhances the original ADV551-P03 with improved reliability, diagnostic functions, and system integration capabilities. Engineered for use in harsh and demanding process environments, it offers enhanced signal isolation, ensuring high immunity against electrical noise and system faults.

Built with Yokogawa’s commitment to long-term support and industrial-grade robustness, the ADV551-P03 S2 is widely deployed in process industries including oil & gas, petrochemical, power generation, and manufacturing plants, providing stable and accurate control outputs.

Product Specifications

Applications

• Process Control Plants: Controls discrete devices such as valves, pumps, and motors in large-scale chemical and petrochemical plants.

• Power Generation Facilities: Provides reliable output for auxiliary systems, alarms, and shutdown controls.

• Oil & Gas Automation: Used extensively in upstream and downstream automation for controlling field instruments.

• Water and Wastewater Treatment: Manages discrete actuators, pumps, and gate valves within treatment plants.

• Pharmaceutical Manufacturing: Enables precise batch control and safety interlock outputs.

• Building Management Systems: Integration with BMS for controlling lighting, HVAC systems, and security devices.

Product Advantages

• Enhanced Reliability: Improved isolation and diagnostics reduce the risk of faults impacting process control.

• High Channel Density: With 32 digital outputs per module, space and wiring complexity are minimized.

• Advanced Diagnostics: Supports short/open circuit detection and module health monitoring to facilitate predictive maintenance.

• Seamless System Integration: Designed specifically for Yokogawa’s CENTUM VP and ProSafe-RS, ensuring smooth operation and easy system configuration.

• Robust Construction: Built to withstand industrial environments with resistance to vibration, temperature fluctuations, and electrical noise.

• Long-Term Support: Yokogawa guarantees availability and support for extended operational lifecycles, helping minimize lifecycle costs.

• Energy Efficient: Low power consumption helps reduce system overhead and heat generation in control cabinets.

Frequently Asked Questions (FAQ)

1. What type of outputs does the ADV551-P03 S2 module provide?
   It provides 32 sink-type open collector transistor outputs designed for 24 V DC loads.

2. Is the module backward compatible with the previous ADV551-P03?
   Yes, the S2 model is backward compatible and can be used as a direct replacement with added features.

3. What is the maximum current rating per output channel?
   Each channel can drive up to 0.5 amperes.

4. Can this module detect output wiring faults?
   Yes, it has diagnostics for open and short circuits on individual output channels.

5. What is the typical update cycle time for the module outputs?
   The output signals update within 100 milliseconds or less.

6. Is the module suitable for use in safety instrumented systems?
   Yes, it is compatible with Yokogawa’s ProSafe-RS safety systems when configured properly.

7. What are the module’s physical dimensions and weight?
   Dimensions are 107.5 × 130 × 32.8 mm, and it weighs 0.2 kg.

8. How is the module powered?
   It receives power via the CENTUM VP base plate in the control system rack.

9. Can the module be replaced while the system is running (hot-swappable)?
   No, the module should be replaced only after the system power is turned off to avoid damage.

10. What environments is the ADV551-P03 S2 rated for?
    It operates reliably between 0 and 55 °C with 5–95% relative humidity (non-condensing).

Related Models (Same Series or Compatible)

Popular Yokogawa Models

Frequently Asked Questions (FAQ)

1. What type of outputs does the ADV551-P03 S2 module provide?
   It provides 32 sink-type open collector transistor outputs designed for 24 V DC loads.

2. Is the module backward compatible with the previous ADV551-P03?
   Yes, the S2 model is backward compatible and can be used as a direct replacement with added features.

3. What is the maximum current rating per output channel?
   Each channel can drive up to 0.5 amperes.

4. Can this module detect output wiring faults?
   Yes, it has diagnostics for open and short circuits on individual output channels.

5. What is the typical update cycle time for the module outputs?
   The output signals update within 100 milliseconds or less.

6. Is the module suitable for use in safety instrumented systems?
   Yes, it is compatible with Yokogawa’s ProSafe-RS safety systems when configured properly.

7. What are the module’s physical dimensions and weight?
   Dimensions are 107.5 × 130 × 32.8 mm, and it weighs 0.2 kg.

8. How is the module powered?
   It receives power via the CENTUM VP base plate in the control system rack.

9. Can the module be replaced while the system is running (hot-swappable)?
   No, the module should be replaced only after the system power is turned off to avoid damage.

10. What environments is the ADV551-P03 S2 rated for?
    It operates reliably between 0 and 55 °C with 5–95% relative humidity (non-condensing).

Related Models (Same Series or Compatible)

Popular Yokogawa Models
