Product Introduction
The Yokogawa AFF50D-H41201 is a Field Input/Output (FIO) Field Control Unit designed to provide reliable control and monitoring capabilities for industrial systems. This unit plays a crucial role in data acquisition and process control by interfacing between field devices such as sensors, actuators, and the main control system. It is designed to offer high performance, versatility, and ease of integration with Yokogawa’s distributed control systems (DCS), particularly in large-scale, complex industrial environments.
This unit is designed for use in industries where real-time process control is essential, such as chemical, petrochemical, power generation, and manufacturing sectors. The AFF50D-H41201 ensures that inputs and outputs from field devices are accurately transmitted to the control system, facilitating precise monitoring and control of plant operations.
Product Parameters
| Parameter | Specification |
|---|---|
| Model | AFF50D-H41201 |
| Type | Field Input/Output (FIO) Field Control Unit |
| Dimensions (W x H x D) | 480 x 290 x 140 mm |
| Weight | 4.54 kg |
| Power Supply | 24 V DC |
| Input Channels | 16 analog inputs, 8 digital inputs |
| Output Channels | 8 analog outputs, 8 digital outputs |
| Communication Protocol | MODBUS, Yokogawa proprietary communication |
| Temperature Range | -10°C to +60°C |
| Environmental Rating | IP20 (dustproof) |
Product Applications
The Yokogawa AFF50D-H41201 Field Control Unit is designed for integration into distributed control systems (DCS) and can be deployed in a wide range of industrial applications including:
-
Petrochemical and Chemical Plants: It facilitates the control of various chemical processes and sensors to ensure optimal conditions.
-
Power Generation: In power plants, it helps manage inputs from field devices like temperature sensors, pressure sensors, and flow meters.
-
Oil & Gas: The unit can monitor and control processes in oil refineries, upstream oil extraction, and gas processing plants.
-
Manufacturing & Automation: Ideal for factory automation systems that require accurate control of machinery and process control equipment.
-
Water Treatment Plants: Used to control and monitor water treatment processes, ensuring efficiency and compliance with environmental standards.
Product Advantages
-
High Reliability: The unit’s robust design and high environmental tolerance ensure reliable operation in demanding industrial settings.
-
Flexible I/O Configuration: With up to 16 analog inputs and 8 digital outputs, it provides excellent flexibility in process control.
-
Seamless Integration: The AFF50D-H41201 integrates seamlessly into existing Yokogawa DCS or third-party systems, offering improved performance and scalability.
-
Real-time Control: Enables precise real-time monitoring and control of processes, improving productivity and reducing downtime.
-
Scalability: Easily scalable for larger systems or additional modules, allowing for future expansion without compromising performance.
FAQ
1. What is the primary function of the Yokogawa AFF50D-H41201 Field Control Unit?
The primary function is to interface between field devices (like sensors and actuators) and the main control system, providing real-time data acquisition and process control.
2. How many analog inputs and outputs does the AFF50D-H41201 support?
The unit supports 16 analog inputs and 8 analog outputs.
3. Can the AFF50D-H41201 be integrated with third-party systems?
Yes, the AFF50D-H41201 can be integrated with both Yokogawa DCS systems and third-party control systems.
4. What types of communication protocols does the AFF50D-H41201 support?
It supports MODBUS and Yokogawa’s proprietary communication protocols.
5. Is the unit suitable for use in hazardous environments?
While the AFF50D-H41201 is rated IP20 (dustproof), it may not be suitable for directly hazardous environments. Appropriate housing or additional protection may be necessary depending on the application.
6. How does the unit handle digital input and output?
The unit supports 8 digital inputs and 8 digital outputs, allowing for basic on/off control and monitoring of field devices.
7. What is the temperature range for operation of the AFF50D-H41201?
The unit can operate within a temperature range of -10°C to +60°C.
8. Can the unit be used in remote locations?
Yes, the unit can be deployed in remote locations as long as appropriate power supply and communication infrastructure are available.
9. What is the environmental rating of the AFF50D-H41201?
The unit has an IP20 rating, making it suitable for environments that are not exposed to excessive dust or moisture.
10. How is the unit powered?
The AFF50D-H41201 is powered by a 24V DC supply.
