Product Overview
The Yokogawa AIP504-10 S1 V Net Coupler Unit is a high-performance network interface module designed for the CENTUM VP distributed control system. It provides a robust and reliable communication link between the V Net network and field devices or sub-systems, enabling real-time data exchange, monitoring, and control.
Key Features
-
High-speed communication interface for V Net networks
-
Reliable integration with CENTUM VP systems and field devices
-
Supports real-time monitoring and control
-
Rugged design for continuous industrial operation
-
Simplifies network management and system expansion
-
Enhances plant automation and operational efficiency
Technical Specifications
| Item | Specification |
|---|---|
| Model Number | AIP504-10 S1 |
| Module Type | V Net Coupler Unit |
| System Compatibility | Yokogawa CENTUM VP |
| Network Interface | V Net digital communication |
| Communication Speed | High-speed, system dependent |
| Operating Temperature | 0 °C to 55 °C |
| Storage Temperature | -20 °C to 70 °C |
| Humidity | 10% to 90% RH (non-condensing) |
| Dimensions | 100 x 100 x 43 mm |
| Weight | 0.5 kg |
| Mounting | DIN-rail or panel mounting |
| Indicators | Status LEDs for network and module operation |
Industry Applications
-
Oil & Gas – Communication interface for field devices and control systems
-
Power Generation – Real-time monitoring and control for turbines and generators
-
Chemical & Petrochemical – Network connectivity for process equipment
-
Water & Wastewater – Integration with sensors, pumps, and control systems
-
Pharmaceutical & Food Processing – Reliable automation network interface
Advantages
-
Provides stable V Net communication for CENTUM VP systems
-
Supports integration of additional devices and system expansion
-
Real-time data acquisition and monitoring for efficient operations
-
Simplifies network management and maintenance
-
Robust design ensures reliable operation in industrial environments
Frequently Asked Questions (FAQ)
Q1: What is the main function of the AIP504-10 S1 module?
It enables reliable communication between V Net networks and CENTUM VP control systems.
Q2: Which systems is it compatible with?
It is compatible with Yokogawa CENTUM VP systems.
Q3: What type of network does it support?
It supports V Net digital communication networks.
Q4: What is the operating temperature range?
0 °C to 55 °C.
Q5: How is the module mounted?
It can be mounted on DIN-rails or control panels.
Q6: What indicators are included?
Status LEDs indicate network connectivity and module operation.
Q7: Can it handle real-time data communication?
Yes, it supports high-speed, real-time data exchange.
Q8: Is it suitable for harsh industrial environments?
Yes, it is designed for reliable operation in industrial conditions.
Q9: What are the module dimensions?
100 mm x 100 mm x 43 mm.
Q10: How much does the module weigh?
Approximately 0.6 kg.
