Product Introduction
The Yokogawa AIP504-51 NET Coupler Module is a dedicated communication interface designed to connect field devices with distributed control systems (DCS) efficiently. It ensures seamless data transfer, reliable network integration, and stable performance for industrial automation applications. This module supports high-speed communication and provides robust connectivity for both standard and redundant network configurations. Its design prioritizes operational stability, minimal maintenance, and compatibility with a wide range of Yokogawa I/O modules.
Product Advantages
-
Reliable Data Communication: Ensures consistent and fault-free data exchange between controllers and field I/O units.
-
Wide Compatibility: Works seamlessly with Yokogawa CENTUM VP and other control platforms.
-
Robust Industrial Design: Resistant to electromagnetic interference, vibration, and temperature variations.
-
Diagnostic and Monitoring Features: LED indicators for quick detection of communication status and faults.
-
Flexible Integration: Supports multiple communication protocols to adapt to different control system architectures.
-
Stable Operation: Designed for continuous operation with minimal intervention.
Technical Specifications
| Parameter | Description |
|---|---|
| Product Model | Yokogawa AIP504-51 NET Coupler Module |
| Function | Network communication and data exchange interface |
| Supported Protocols | Yokogawa proprietary protocol, Ethernet-based communications |
| Power Supply Voltage | 24 V DC nominal |
| Power Consumption | Approximately 6 W |
| Operating Temperature Range | 0 to 55 °C |
| Storage Temperature Range | -20 to 70 °C |
| Communication Interface | Dual redundant communication ports |
| Indicators | LED indicators for communication and status |
| Cooling Method | Natural air cooling |
| Dimensions | 200 × 130 × 40 mm |
| Weight | 0.5 kg |
| Mounting Type | Rack-mounted or panel-mounted installation |
| Certifications | CE, UL, and CSA compliant |
| Compatibility | Compatible with Yokogawa control systems and I/O modules |
Product Applications
-
Process Automation Systems: Efficient signal communication between distributed control nodes.
-
Power Generation Plants: Stable monitoring and control of turbines, boilers, and generators.
-
Oil and Gas Operations: Data acquisition and coordination for upstream and downstream processes.
-
Chemical and Petrochemical Plants: Integration with safety and control systems.
-
Manufacturing Automation: Synchronization between PLCs, robotic systems, and controllers.
-
Water Treatment Facilities: Centralized monitoring and remote control of distributed instrumentation.
FAQ
Q1: What is the primary function of the AIP504-51 NET Coupler Module?
A1: It functions as a communication interface that links field devices to the control system network, ensuring real-time, reliable data transfer.
Q2: Does the module support redundant communication paths?
A2: Yes, it has dual redundant communication ports to maintain data integrity in case of a network failure.
Q3: Can it integrate with existing Yokogawa CENTUM VP systems?
A3: Yes, the module is fully compatible and can be seamlessly integrated into CENTUM VP and other Yokogawa control platforms.
Q4: How does the AIP504-51 handle communication errors?
A4: Built-in diagnostics detect errors automatically, and the module can switch to backup channels if redundancy is configured.
Q5: What network topologies are supported?
A5: The module supports star and ring topologies, depending on the control system configuration.
Q6: Are there indicators for network activity and errors?
A6: Yes, front panel LEDs display link status, data activity, and fault conditions.
Q7: What is the recommended operating voltage range?
A7: The module operates at 24 V DC nominal, with an acceptable range of ±10%.
Q8: Can firmware updates be performed in the field?
A8: Yes, using Yokogawa configuration tools via communication ports.
Q9: Is there isolation between communication and power circuits?
A9: Yes, galvanic isolation is provided to protect the network and maintain safety.
Q10: How is the module protected from electromagnetic interference (EMI)?
A10: It includes advanced shielding and filtering to comply with industrial EMC standards, ensuring stable operation.
Related or Same-Series Models
| Model | Description |
|---|---|
| AIP502-51 | Standard NET Coupler Module |
| AIP503-51 | High-speed NET Coupler Module with enhanced features |
| AIP505-51 | Advanced redundancy NET Coupler Module |
| AIP506-51 | NET Coupler for expanded I/O system integration |
| AIP507-51 | Enhanced communication NET Coupler Module |
| AIP508-51 | NET Coupler with diagnostics and fault tolerance |
Popular Models from the Same Brand
| Model | Product Type | Description |
|---|---|---|
| AAI141-H53 | Analog Input Module | High-density analog input for precise signal capture |
| ADV151-P00 | Power Supply Module | Provides reliable power to control systems |
| AAM11-S3 | Analog Output Module | Outputs accurate analog signals for control systems |
| ANB10D-420 | Field Control Unit | Central controller for distributed I/O systems |
| AFV10D-S1 | CPU Communication Module | Handles system-level data communication |
| AMM22-S3 | Analog Input/Output Module | Dual-function I/O module for flexible applications |
