Product Overview
The Yokogawa AIP512 V-Net Coupler Module is designed to provide reliable communication and interface between the V-Net network and field devices in Yokogawa’s DCS (Distributed Control System) architecture. It enables seamless data transfer, ensuring real-time monitoring, control, and integration of field instrumentation into the process control environment. The module supports multiple field devices while maintaining high-speed communication and system reliability.
Key Features
-
Facilitates communication between V-Net field devices and DCS systems
-
High-speed data transfer for real-time process monitoring
-
Supports multiple field devices with robust connectivity
-
Compact and rack-mountable design for easy integration
-
Maintains system reliability under industrial operating conditions
-
Ensures accurate and synchronized data collection
-
Compatible with Yokogawa CENTUM VP systems
Technical Specifications
| Item | Specification |
|---|---|
| Module Type | V-Net Coupler Module |
| Model Number | AIP512 |
| Network Compatibility | Yokogawa V-Net |
| Supported Devices | Multiple field devices on V-Net |
| Communication Speed | High-speed V-Net protocol |
| Rack Compatibility | Yokogawa DCS rack systems |
| Power Supply | Provided via rack backplane |
| Operating Temperature | 0°C to 55°C |
| Storage Temperature | -20°C to 70°C |
| Humidity | 5% to 95%, non-condensing |
| Dimensions | 152 x 76 x 254 mm |
| Weight | 0.2 kg |
Industry Applications
-
Process automation in chemical, petrochemical, and oil & gas industries
-
Power generation plants – integrating field devices with DCS
-
Water and wastewater treatment – reliable monitoring and control
-
Pharmaceutical production – accurate process data collection
-
Industrial automation systems – high-speed communication with field instrumentation
Frequently Asked Questions (FAQ)
Q1: What is the primary function of the AIP512?
It acts as a coupler between V-Net field devices and the DCS system, enabling data communication and control.
Q2: Is it compatible with Yokogawa CENTUM VP systems?
Yes, it is fully compatible with CENTUM VP DCS racks and systems.
Q3: How many devices can it support?
It supports multiple field devices connected via V-Net.
Q4: What is the operating temperature range?
0°C to 55°C.
Q5: Can it be mounted in standard racks?
Yes, it is designed for Yokogawa DCS rack systems.
Q6: How is it powered?
It receives power from the rack backplane.
Q7: Does it support high-speed communication?
Yes, it ensures fast and reliable data transfer on V-Net.
Q8: What kind of data does it handle?
Process measurements, status signals, and control commands from field devices.
Q9: Can it operate in industrial environments?
Yes, it is designed to withstand typical industrial temperature and humidity conditions.
Q10: Is installation complicated?
No, it is a plug-in module for Yokogawa racks, simplifying integration.
Related Models
| Model Number | Description |
|---|---|
| AIP511 | V-Net Coupler Module (previous generation) |
| AIP513 | Advanced V-Net Coupler Module |
| AIP515 | V-Net Coupler with extended device support |
| AIP516 | V-Net Coupler with diagnostic support |
| AIP518 | V-Net Redundant Coupler Module |
| AIP520 | High-capacity V-Net Coupler Module |
