Product Overview
The Yokogawa AIP532 S1 ESB Bus Coupler Unit is a high-performance interface module that connects the ESB (Embedded System Bus) to Yokogawa distributed control and safety systems. It provides reliable communication between the ESB network and I/O or CPU modules, ensuring stable and high-speed data transfer across system components. The AIP532 S1 is designed for robust industrial operation, supporting fault tolerance and easy integration into CENTUM VP and ProSafe-RS systems.
Key Features
-
High-speed communication between ESB and system modules
-
Reliable bus coupling for distributed control networks
-
Supports redundancy for continuous system operation
-
Robust industrial design suitable for harsh environments
-
Integrated diagnostics for fault detection and monitoring
-
Hot-swappable capability to minimize downtime
-
Compatible with CENTUM VP and ProSafe-RS platforms
Technical Specifications
| Item | Specification |
|---|---|
| Module Type | ESB Bus Coupler Unit |
| Model Number | AIP532 S1 |
| System Compatibility | Yokogawa CENTUM VP, ProSafe-RS |
| Bus Type | ESB (Embedded System Bus) |
| Data Rate | High-speed (system dependent) |
| Redundancy | Supported |
| Diagnostics | Bus health monitoring, status indication |
| Hot-Swappable | Yes |
| Operating Temperature | 0°C to 55°C |
| Storage Temperature | -40°C to 85°C |
| Humidity | 5% to 95% RH (non-condensing) |
| Dimensions | 130 × 28 × 130 mm |
| Weight | 0.45 kg |
| Cooling Method | Natural convection |
Industry Applications
-
Oil & Gas – Reliable ESB communication for process automation
-
Power Generation – High-speed data transfer for turbine and boiler control
-
Chemical & Petrochemical – Linking control and safety I/O modules
-
Pharmaceuticals – Ensuring fault-tolerant distributed control communication
-
Water & Wastewater – Stable communication for monitoring and control systems
-
Pulp & Paper – Connecting distributed I/O and CPU modules
Frequently Asked Questions (FAQ)
Q1: What is the function of the AIP532 S1 module?
It connects the ESB network to I/O and CPU modules, enabling reliable communication.
Q2: Which systems is this module compatible with?
It is compatible with Yokogawa CENTUM VP and ProSafe-RS systems.
Q3: Does it support redundancy?
Yes, the module supports redundant ESB network configurations.
Q4: Can the module be replaced without shutting down the system?
Yes, it is hot-swappable.
Q5: What type of bus does it interface with?
It interfaces with the Embedded System Bus (ESB).
Q6: What diagnostics are included?
It provides bus health monitoring and status indication.
Q7: What is the operating temperature range?
It operates between 0°C and 55°C.
Q8: How is the module cooled?
It uses natural convection cooling.
Q9: What are the module dimensions?
Approximately 130 mm × 28 mm × 130 mm.
Q10: How much does the module weigh?
It weighs approximately 0.45 kg.
Related Modules
| Model Number | Description |
|---|---|
| AIP532 S1 | ESB Bus Coupler Unit |
| AIP521 S1 | Control Bus Coupler Module |
| AIP512 | V-Net Coupler Module |
| NFCP502-W05 | CPU Module |
| NFDR541 | Relay Output Module |
| NFAR181-S00 | RTD Input Module |
